Charles McMurray Co. 2023 Catalog

656 / 1645

• Pre-assembled bottom-mount set
• MOVENTO heavy-duty full-extension concealed
runners with BLUMOTION
• For 13 (1/2") to 16 (5/8") drawer side thickness
• 19 (3/4") over-extension
• For face frame and frameless applications
• Tool-free side-to-side, height and tilt adjustment
• Maximum 6 (1/4") cabinet bottom recess
• Load rating 135 lbs.
• Designed to be used with SERVO-DRIVE touch-to-
open feature (order separately)
• Overall cabinet depth 610 (24")
MOVENTO Waste/Recycle Set with SERVO-DRIVE Capability
For 21" Drawer Length
Set includes:
MOVENTO 21" heavy-duty runner set with pre-mounted
#6x1" wood screws (qty 8)
Standard locking devices (1 pr BT51.7601) with #6x5/8"
wood screws
Installation template and instructions
Note: Drawer and bins not included
Set No.
Minimum
Opening
Drawer
Length List Set
15" W 533 (21") $165.12
18" W 533 (21") $165.12
Notes: Drawer and bins not included.
SERVO-DRIVE sold separately.
TIP-ONBLUMOTIONsoldseparately.
See page 663 for Western Dovetail drawer boxes.
KV 35 quart bins (order separately) - 14-1/4"W x 9-3/16"D x 17-1/2"H
Item No. Color List Ea.
Silver $43.32
Set includes:
Drive unit (pre-attached)
Screw-on distance bumpers (qty 4) with #6x5/8" wood screws (qty 8)
Double bottom bracket with #6x1" wood screws (qty 2)
INSERTA cable connector
Adapter plate
Cable end protectors (qty 2)
Cable clips (qty 4)
110V plug-in power supply with six feet of universal cable
Installation template, instructions and user manual
SERVO-DRIVE for Waste/Recycle Set
NOTE: Power supply will operate up to two drive units in a double bottom bracket application. (Only 1 drive unit included in set.)
Set No. List Set
$618.12
Door opens automatically with
just a touch of the cabinet front
or a light pull of the handle.
(1-5/8" required space behind drawer)
NOTES:
Cabinet bottom recess must be 6 (1/4") or less.
Interior roll-outs and roll-out shelf applications must be mounted to the
bottom of the cabinet or to a fixed shelf/panel.
Rear brackets and sockets cannot be used. Cabinet bottommust be flush
with top surface of bottom rail unless bottom-mount spacers are used.
Bulk slides only, for custom and wide
drawers (no crossrail). Includes standard
locking devices. NOTE: Pre-attached
1/4" spacers should not be removed.
Item No. List Pr.
$149.18
One set required per drawer
