Institutional Hinges
5-Knuckle
• Hole pattern: 32 mm centers
with 37 mm setback
• 2-3/4" height five-knuckle hinge
• Hospital tips
• 270° opening angle
• Door overlay 15/32"
• Mounting holes are countersunk for #8 flathead screws
• Adjustable screw holes
• Exceeds ANSI/BHMA 156.9 Grade 1
• Powder-coat dull chrome finish
100 each per box without screws. Sold per each.
Item No.
Side
Panel
Door
Thickness Finish List Ea.
3/4" 3/4" Powder Chrome $5.36
3/4" 3/4" Powder Chrome $6.30
Screws
Item No. Description List c
#8 x 5/8" FH $5.94
#8 x 3/4" FH $6.40
door
thickness
side
panel
hinge
overlay
door
overlay
Institutional Hinges
5-Knuckle
• Hole pattern:
32 mm centers with 37 mm
setback, 51mm(2") doorwing
• 2-3/4" height
• Countersunk mounting holes
for #8 flathead screws
• Adjustable screw holes
• ExceedsANSI/BHMA156.9-15
100 each per box without screws. Sold per each.
Item No.
Side
Panel
Door
Thickness Finish List Ea.
3/4" 13/16" Stainless Steel $15.12
Screws
Item No. Description Finish List c
#8 x 5/8" FH Zinc $5.94
#8 x 3/4" FH Zinc $6.40
Polybagged (450 ea.)
#8 x 5/8" FH Stainless Steel $74.64
• Hole pattern: 32 mm centers
with 37 mm setback; RP454 wing
holes 45 mm on center
• 2-3/4" height five-knuckle hinge
• Hospital tips
• 270° opening angle
• Drilled knuckle ID w/precision drawn pins
• Mounting holes are countersunk for #8 flathead screws
• Adjustable screw holes
• Exceeds ANSI/BHMA 156.9 Grade 1
• Dull chrome finish
32 MM
COMPATIBLE
2-1/2" five-knuckle hinge with hospital tips. Stocked in dull chrome
finished steel. Uses #8 x 5/8" FH wood screws. 50 pair per box
with screws. Sold per pair.
Item No. Finish List Pr.
List Pr.
Full Box
Dull Chrome $25.36 $22.70
Screws
Item No. Description List c
#8 x 5/8" FH $5.94
3/4" door
thickness
1-59/64"
7/32"
door clearance
Institutional Hinges
For Overlay Doors
Institutional Hinge
For Flush Doors
Rockford
Process
Control
Rockford
Process
Control
door
thickness
side
panel
hinge
overlay
door
overlay
50 pair per box without screws. Sold per pair.
Item No.
Side
Panel
Door
Thickness
Hinge
Overlay
Door
Overlay List Pr.
3/4" 3/4" 23/32" 15/32" $19.92
3/4" 13/16" 23/32" 15/32" $19.70
100 per box without screws. Sold per each. Not WI Approved.
Item No.
Side
Panel
Door
Thickness
Hinge
Overlay
Door
Overlay
List
Ea.
3/4" 3/4" 23/32" 15/32" $10.16
Screws
Item No. Description List c
#8 x 5/8" FH $5.94
#8 x 3/4" FH $6.40
