Invisible Hinges

For use with wood or metal doors. Use for custom furniture,

cabinetry, displays... wherever a smooth, flush appearance

is important. Ideal for mirrored or appliquéd doors and

panels, pass doors, electronic cabinets, communication and

computer room doors and security. Templates are available

on special order.

See following page to determine type and number of

hinges per application.

Heavy-Duty Applications

Medium-Duty Applications

Light-Duty Applications

1 pair per card with wood screws.

Sold per pair.

1 each per box with wood screws.

Sold per each.

Item No.

Height (C)

Finish

List Pr.

SS101US4

1-11/16"

Satin Brass

$59.86

SS103US4

1-1/2"

Satin Brass

$56.26

SS203US4

1-3/4"

Satin Brass

$66.16

SS204US4

2-3/8"

Satin Brass

$73.66

SS103US26D

1-1/2"

Satin Chrome $56.26

SS203US26D

1-3/4"

Satin Chrome $66.16

SS204US26D

2-3/8"

Satin Chrome $73.66

1 each per box with wood screws.

Sold per each.

Item No.

Height (C)

Finish List Ea.

SS216US26D-EACH

4-5/8"

Satin Chrome $133.00

SS218US26D-EACH

4-5/8"

Satin Chrome $137.60

Item No.

Height (C)

Finish List Ea.

SS208US26D-EACH

2-3/4"

Satin Chrome $45.36

SS212US26D-EACH

3-3/4"

Satin Chrome $85.84

SS212US4-EACH

3-3/4"

Satin Brass $85.84

Hinge Measurements

SS101US4 SS103US4 SS203US4 SS204US4 SS208US26D-EACH SS212US4-EACH SS218US26D-EACH SS103US26D SS203US26D SS204US26D
