Charles McMurray Co. 2023 Catalog

218 / 1645

Boring Pattern
NOTE:
Maximum door
thickness 3/4"
Minimum Reveal
minimum reveal
3/4" door = 7/32"
based on square
edge doors
250 per box. Sold per each. Screws not included.
(Order #8 x 3/4" flathead screws.)
BLUMOTION Soft-Close
Item No. Overlay Mounting List Ea.
List Ea.
100
List Ea.
250
Wrap-Around
1" Press-in $8.52 $8.02 $7.18
1-1/4" Press-in $8.52 $8.02 $7.18
1-3/8" Press-in $8.52 $8.02 $7.18
1-1/2" Press-in $9.38 $8.82 $7.90
COMPACT CLIP BLUMOTION 31C3 - 110° Opening
Two-Piece Hinge, Full Overlay
Accessories
Item No. Description List Ea.
B38C315B3.1 Angle Restriction Clip (86°) $0.82
B38C355B9 Hinge Cup Spacer $4.46
Blank Cover Cap $0.96
Ram $83.90
Wrap-Around
Adjustment
NOTE: COMPACT BLUMOTION comes in the activated position, marked
with a "|". The deactivated position is marked with an "0".
Dimensions
Adjustments
Depth +3/32", -1/32"
Height ±5/64"
Side ±1/16"
COMPACT Accessories.......... pg. 219
Features
• Available in BLUMOTION Soft-Close
• Two-piece wrap-around hinge with CLIP technology
• 1/2" cup depth
• Less minimum reveal
• Three-dimensional cam adjust
• Press-in hinges must be inserted with knock-in tool
or COMPACT insertion ram
05/24
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
CABINET HINGES
800.533.0533 218 Prices subject to change without notice.
