Charles McMurray Co. 2023 Catalog

1280 / 1645

Residential Single-Acting Spring Hinges
1/4" or 5/8" Radius
Non-Template
Maximum Door Size: 3'0" x 7'0"
Full mortise, adjustable tension, 3-knuckle. For maximum
versatility use all spring hinges. Full spring tension may not be
required on all hinges.
Screws are included. Sold per pair.
1/4" Radius
Item No. Finish Size Box List Pr.
Antique Bronze 3-1/2" 40 pr $29.58
Satin Nickel 3-1/2" 40 pr $29.58
Matte Black 4" 40 pr $39.02
Antique Bronze 4" 40 pr $39.02
Satin Nickel 4" 40 pr $39.02
5/8" Radius
Satin Nickel 3-1/2" 40 pr $29.58
Matte Black 4" 40 pr $39.02
Antique Bronze 4" 40 pr $39.02
Satin Nickel 4" 40 pr $39.02
Polished Chrome 4" 40 pr $39.02
Hinge Size Max. DoorWeight Spring Hinges Butt Hinges
3-1/2" 70 lbs. 2 1
4" 70 lbs. 2 1
Hinge Size Numberof Holes
Gauge
of Metal
Wood
Screw Size
3-1/2" 6 .106 3/4" x 9 FH
4" 8 .106 1" x 9 FH
4"
Residential Double-Acting Spring Hinges
Adjustable (with screws). Recommended for light-duty applica-
tion only. Satin brass finish. Sold per each.
Item No. Size Box List Ea.
List Each
Full Box
3" 10 ea $56.40 $53.34
4" 10 ea $68.46 $64.72
5" 10 ea $112.24 $106.12
6" 10 ea $112.24 $106.12
Maximum Door Sizes & Weights - 3 hinges
Hinge
Size
Door
Weight
Max. Door
Size
Door
Thickness
3" 35 lbs. 2'8" x 5' 3/4 to 1"
4" 75 lbs. 3'0" - 6'8" 7/8 to 1-1/4"
5" 90 lbs. 3'0" - 6'8" 1-1/8 to 1-1/2"
6" 100 lbs. 3'0" - 7' 1-1/4 to 2"
3-1/2"
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 1280 Prices subject to change without notice.
