Manual Boring Template
For Hinges and Mounting Plates
Mounting Plate Template
• For boring Ø8 mm dowel holes after Ø35 mm hole is bored
• Also bores 5 mm holes for system screw mounting plates
• Includes drill stop collar to pilot bore 2.5 mm for screw-on plates
• Order bits separately 2.5 mm and 5 mm)
• Use with CLIP mounting plates on overlay applications
on panel cabinets
• For wing mounting plates (37 mm setback) and in-line
mounting plates (20 mm setback)
• Simple location of mounting plate screw positions
• Pilot bore Ø2.5 mm holes for wood screws
Item No. For Hinges List Ea.
107, 110, 120 $155.46
Compact Hinges $83.90
*Not for wide angle hinges or specialty hinges. Can be used with 95°
and 100° by adjusting ball plungers.
Insertion Rams
For Hinge Installation
Item No. List Ea.
$30.50
Item No. List Ea.
$93.12
• For marking and pre-boring of wing or in-line mounting plates
• Can be used for marking and pre-boring BLUMOTION and TIP-ON
adapter plates
• Can be used for pre-boring AVENTOS locating pins
• Can be used for marking and pre-boring cabinet profiles
• Calibrated scale with preset positions for common applications
Universal Individual Template
Item No. Description List Ea.
Template $219.90
5 mm Bit $20.74
3/32" Bit (2.5 mm) $3.74
• Accurate hinge positioning with built-in indexing tabs
• Repeatable results with built-in measuring scales
• Reliable drilling with bit guide and stop collar
• Adjustable cams ensure proper hinge offset
• Durable carbide-tipped drill bit included
• Hinge offset 3 mm, 4 mm, 5 mm, 6 mm
• Hinge offset from door end 2" to unlimited
Concealed Hinge Jig
Set includes:
Universal individual template
Ø2.5 mm and Ø5 mm stop collars
Includes:
Jig base with index cams
Drill guide
35 mm carbide-tipped drill bit
Stop collar with Hex wrench
Item No. List Ea.
$66.08
Templates & Jigs
Cabinet Hinges & Baseplates
Compatible
with any drill.
11/24
ECODRILL
for Hinge Boring
• For precisely drilling the Blum hinge pattern
• Driven by an electric hand drill or cordless drill (18v or higher)
• Variable drilling distance (from 2 to 8 mm)
• One-handed clamping with easy adjustment for door thickness
up to 40 mm (1-9/16")
• Side stops and integrated angle template
• Includes drill bits (pre-installed) and TORX driver bits
Includes:
(1) drilling template
(2) 8 mm drill bits
(1) 35 mm drill bit fitting
(2) TORX bits
(2) adjustable clamps
Item No. List Ea.
$1,104.04
