Templates & Jigs
Tectus Concealed Hinge Templates
Anselmi Concealed Hinge Templates
Universal Milling Frame
See below for router bit size (1" collar ring). Sold per kit.
Kit No.
Hinge
List Kit
TE340-3D-TMP
TE340
$266.95
TE340-3D-EK-TMP
TE340 EK
$423.56
TE540-3D-TMP
TE540
$266.95
TE540-3D-A8-TMP
TE540 A8
$400.42
TE540-3D-EK-TMP
TE540 EK
$423.56
TE541-3D-FVZ-TMP
TE541 FVZ
$533.90
TE640-3D-TMP
TE640
$266.95
For Anselmi concealed hinges. (1/2" router bit, 1" collar ring)
Sold per each.
Item No.
Hinge
List Ea.
AN161-TMP
AN161 FVZ
$156.61
AN170-TMP
AN170
$156.61
Fitting installation aid for Anselmi and Tectus concealed hinge
templates. Includes frame and clamping device. Sold per each.
Item No.
List Ea.
TE-MILLING-FRAME
$1,101.69
Kit
Component Description Bit
TE340-3D-TMP
251058
Step 1
3/4"
251059
Step 2
3/4"
TE340-3D-EK-TMP
251058
Step 1
3/4"
251059
Step 2
3/4"
251082
Raceway
3/4"
TE540-3D-TMP
251060
Step 1
3/4"
251061
Step 2
3/4"
TE540-3D-A8-TMP
251060
Step 1
3/4"
251061
Step 2
3/4"
251068
Step 3
3/4"
TE540-3D-EK-TMP
251060
Step 1
3/4"
251061
Step 2
3/4"
251082
Raceway
3/4"
TE541-3D-FVZ-TMP 251071
Frame, Step 1
3/4"
251072
Frame, Step 2
3/4"
251068
Frame, Step 3
3/4"
251071
Door, Step 1
3/4"
251072
Door, Step 2
3/4"
251073
Door, Step 3
3/4"
TE640-3D-TMP
251062
Step 1
3/4"
251063
Step 2
3/4"
Routers
AN161-TMP
AN170-TMP
FVZ = Recessed frame facing
EK = Energy Kit
A8 = Cladded
For hinges see pgs. 1286-1287e
