Charles McMurray Co. 2021 Catalog

908 / 1590

1-1/2"
1-1/2"
rout
to 9/32"
depth
back of
backsplash
rout to back
of laminate
Allows you to formfit a backsplash to nearly anywall surface.
• Formfitting • No metals
• Waterproof • Eliminates scribing
• No visible caulk • Installs in minutes
Item No. Box List Ea.
List Ea.
250
250 $2.16 $1.32
Rout the laminated backsplash.
Run a bead of caulk along the
front of Smart Clips ® , and drive
the backsplash into position.
After measuring and drilling at 12" intervals on the backsplash,
install screws (included) into the bottom of the backsplash.
1
2
3
4
wall
Install the Smart Clip® on the countertop, butting the wall,
using the screws provided.
counter
back of backsplash
Smart Clips® may be placed over back of counter
1/4" to allow for differences in wall. This will allow
the backsplash to conform to the wall.
wall
counter
The Smart Clip™
2" x 11/16" wide.
Undermount Sink Brackets
Pair includes (2) inner and (2) outer channels, (10)
wood screws, (4) assembly bolts, (2) nuts, leveling
bolts and caps, and (4) side plates.
For resetting sinks in existing counter tops, or installing
after counter installation.
Pair includes (1) long channel set, (1) short channel set,
(1) offset bar (flips over for left or right offset), (10)
wood screws, (10) assembly bolts, (2) nuts, leveling
bolts and caps, and (2) side plates .
See pg. 769 for Counter Top brackets.
Item No. Box List Pair List Pair 6
6 pr $43.82 $38.95
6 pr $72.00 $58.71
Adjustable front to back
for 14" to 26" cabinets
Adjustable left or right
for 31" to 47" cabinets
FOR STAINLESS STEEL 60/40 SINKS
FOR CAST IRON SINKS
05/22
1. Install brackets to fit cabinet and sink size.
2. Set sink on brackets.
3. Adjust leveling screws until sink is level and at
desired height.
