Bracket Set
TANDEMBOX - M Height (3-5/16") - Gray Finish
Dynamic Weight Capacities of 75 lbs. and 150 lbs.
Sold per kit (components also available individually).
Each kit includes:
1 pair Drawer Profiles
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each INSERTA Front Fixing Brackets
BZ30M
Rear Fixing
Bracket Set
Front
Fixing Bracket
BZ31L1036A Front Piece
Required for interior rollout.
Not included in kit.
Order separately.
Sold per kit (components also available individually).
Each kit includes:
1 pair Drawer Profiles
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
1 pair Interior Front Brackets
Front piece must be ordered separately (BZ31L1036).
Components
B378M Drawer Profile Set B578/576 Cabinet Profile Set
1036mm (40-13/16") (cut to size)
L=inside cabinet width minus
132 (5-3/16")
Interior Rollout Drawers Standard Drawers
Recommended Fasteners
Slides: #7x5/8" flathead (MCFPT587)
Rear Brackets: #6 x 1/2" trusshead
For a complete list of components
see catalog pages 464-465.
Drawer Height: 84mm (3-5/16").
Minimum Opening Height: 98.5mm (3-7/8") based on 3mm (1/8")
clearance.
Minimum depth = actual profile length +3mm (1/8").
Drawer Height: 84mm (3-5/16").
Minimum Opening Height: 136.5mm (5-3/8") based on 3mm (1/8")
clearance. With handle application 106mm (4-3/16").
Minimum depth = actual profile length +3mm (1/8").
Item No.
Nominal
Length
Actual
Length List Per Kit
75 lb. Capacity
TB-M-270G 11" 10-5/8" $121.90
TB-M-350G 14" 13-3/4" $121.90
TB-M-400G 16" 15-3/4" $126.10
TB-M-450G 18" 17-11/16" $128.18
TB-M-500G 20" 19-11/16" $131.28
TB-M-550G 22" 21-5/8" $135.30
150 lb. Capacity
TB-M-450G150 18" 17-11/16" $154.26
TB-M-500G150 20" 19-11/16" $156.46
TB-M-550G150 22" 21-5/8" $161.48
NOTE: Some sizes require a lead-time.
Item No.
Nominal
Length
Actual
Length List Per Kit
75 lb. Capacity
TB-M-270G-INT 11" 10-5/8" $132.24
TB-M-350G-INT 14" 13-3/4" $132.24
TB-M-400G-INT 16" 15-3/4" $136.44
TB-M-450G-INT 18" 17-11/16" $138.52
TB-M-500G-INT 20" 19-11/16" $141.62
TB-M-550G-INT 22" 21-5/8" $145.64
150 lb. Capacity
TB-M-450G-INT150 18" 17-11/16" $164.60
TB-M-500G-INT150 20" 19-11/16" $166.80
TB-M-550G-INT150 22" 21-5/8" $171.82
