Invisible Hinges

For use with wood or metal doors. Use for custom fur-

niture, cabinetry, displays. . . wherever a smooth, flush

appearance is important. Ideal for mirrored or appliquéd

doors and panels, pass doors, electronic cabinets, commu-

nication and computer room doors and security. Templates

are available on special order.

See following page to determine type and number

of hinges per application.

Heavy-Duty Applications

Medium-Duty Applications

Light-Duty Applications

1 pair per card with wood screws.

Sold per pair.

1 each per box with wood screws.

Sold per each.

Item No.

Height (C)

Finish

List Pr.

SS101US4

1-11/16" Satin Brass

$53.86

SS103US4

1-1/2"

Satin Brass

$47.82

SS103US26D

1-1/2"

Satin Chrome

$47.82

SS203US4

1-3/4"

Satin Brass

$59.54

SS203US26D

1-3/4"

Satin Chrome

$59.54

SS204US4

2-3/8"

Satin Brass

$61.34

SS204US26D

2-3/8"

Satin Chrome

$61.34

1 each per box with wood screws.

Sold per each.

Item No.

Height (C)

Finish List Ea.

SS216US4-EACH

4-5/8" Satin Brass

$113.04

SS216US26D-EACH

4-5/8" Satin Chrome $113.04

SS218US26D-EACH

4-5/8" Satin Chrome $114.68

Item No.

Height (C)

Finish

List Ea.

SS208US26D-EACH

2-3/4" Satin Chrome

$37.82

SS212US4-EACH

3-3/4" Satin Brass

$71.54

SS212US26D-EACH

3-3/4" Satin Chrome $71.54

Hinge Measurements
