Charles McMurray Co. 2021 Catalog

1348 / 1590

Rolling Door Hardware - Round Rail
Accessories
Rail Door Stop
Stops the rolling door from the top instead of the bottom. Mounts
onto the round rail. Includes a rubber ring to protect door hard-
ware. Fasteners are included.
Note: Additional center floor guides are required to keep door
rolling in a straight path.
Item No. Finish List Ea.
Satin Nickel $44.34
Oil-Rubbed Bronze $44.34
Black $44.34
Bypass Door Bracket Add-On Kit
Item No. Finish List Kit
Black $74.92
Bronze $52.88
Satin Nickel $74.92
Includes:
1 Wall Mount Bracket
1 Rail Bracket
All necessary fasteners
NOTE: Order 5 kits for 6' rails.
Order 6 kits for 8' rails.
Wall Mount
Bracket Rail Bracket
Height 5-5/8" 2-9/16"
Width 3-1/4" 1"
Projection 3-1/4" 1-1/16"
wall mount bracket
rail bracket
wall mount bracket
rail bracket
Item No. Length Finish List Ea.
4’ Satin Nickel $137.18
4’ Oil-Rubbed Bronze $137.18
4’ Black $126.80
6’ Satin Nickel $194.72
6’ Oil-Rubbed Bronze $194.72
6’ Black $183.40
8’ Satin Nickel $255.86
8’ Oil-Rubbed Bronze $255.86
8’ Black $237.74
Splice Kit
1/2" x 1/8" bar $26.94
Separate rail lengths to build custom length doors. Combine any
of the lengths of rail sold here using the splice kit sold below.
Used to mount the rail to the wall. We recommend 16" spacing
between brackets. Sold per each with screws. Choose from short
or long bracket sizes. Shown with rail attached.
Item No. Type Finish List Ea.
Long Satin Nickel $28.58
Long Oil-Rubbed Bronze $28.58
Long Black $24.50
Short Satin Nickel $26.94
Short Oil-Rubbed Bronze $26.94
Short Black $24.50
Item No. Finish List Kit
Satin Nickel $58.86
Oil-Rubbed Bronze $58.86
Black $56.60
Black $129.84
QG401
QG40
Tap to thread rail for end stops.
Item No. List Ea.
$21.42
2-5/8"H x 1"w
1-3/4" projection w/rail
QG203 short bracket
(Doors up to 1-1/2")
2-5/8"H x 3/4"w
2-3/8" projection w/rail
QG201 long bracket
(Doors up to 2-1/4")
1" dia.
Select Round Rail 3
Select Wall Mounting Brackets 4
Select End Stops (2 per kit) 5
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 2021 1946 1348 Prices subject to change without notice.
