Accessories
1211 Guide Roller: For use with 1222 guide chan-
nel. Attaches to door bottom and runs within guide
channel. Door mortising not required. Dimensions:
plate 2" x 3/4" x 3/32", roller 17/32" x 1/2" dia.
Zinc plated steel.
Item No. Box List Ea.
List Ea.
Full Box
20 $10.36 $12.94
1221 Door Guide: For use with 1222 guide channel.
Attaches to bottom of lead door and runs in guide
channel. 3/4"x3-1/2"x3/32". Zinc-plated steel plate
and post. Guide roller is oilite bronze.
Item No. Box List Ea.
List Ea.
Full Box
20 $30.70 $26.10
1222 Continuous Guide Channel: For use
with 1211 or 1221 guide roller. Mortised into floor
or surface mounted. 5/8"H x 3/4"D. Aluminum
.093" thick.
Item No. Length Box List Ea.
List Ea.
Full Box
8' 5 $80.46 $67.54
12' 5 $113.52 $96.20
Framing and Panel Sizes:
Finished opening to be a minimum of panel height plus 4-1/4".
(Allows no adjustment.)
Maximum vertical adjustment top of door to header is 1/2".
Maximum vertical adjustment bottom of door to floor is 1".
Maximum adjustment header to floor is 1-1/2".
Hardware Set Includes
1 1205 carrier with pendant bolt &top plate 1 1234 bottom pivot plate assembly
1 1223 floor pivot bolt assembly 1 1269 top pivot post assembly
1 1224 bottom pivot pin plate 1 1255 top pivot clamp assembly
screws & instructions
1223 floor pivot bolt
assembly
1255 top pivot
clamp assembly
1269 top pivot post
assembly
1224 bottom pivot pin plate 1234 bottom pivot plate assembly
1201 track, sold separately
1205 carrier w/pendant
and top plate
Components
Heavy-Duty Bi-Fold Door Hardware
For Doors 1" Minimum, Up To 175 lbs. Each
For 1" or thicker doors.
Adjustment: 0" to 1-1/2" vertical.
Headroom: 3-1/4 to 3-3/4".
Using door guide channel 1222
and door guide 1221 mortised
into floor or surface mounted.
Bulk Pack - Track & hardware sold separately
Track
Item No. Length Box List Ea.
List Ea.
Full Box
8' 5 ea $122.52 $103.84
12' 5 ea $166.92 $142.70
Hardware Set
Item No. Box List Set
List Set
Full Box
5 sets $227.28 $192.62
• For door panels 1" minimum and up
• 4-wheel carrier with precision ball-bearing wheels for
quiet, effortless operation
• Aluminum I-beam track, pre-drilled for easy installation
• Meets and/or exceeds ANSI/BHMA standards
Floor guide channel and door guide are optional, and available sepa-
rately.
