No.
FES-5762441 hp Module Edge/Trim Router
MFK 700 EQ/B-Plus
No.
FES-5762391 hp Module Edge/Trim Router
MFK 700 EQ-Set
Features:
• Precision depth control
• Variable speed control
• Specially designed for flush trimming and rounding protruding
edge
• Possible to flush trim 0 to 45 degree inclined edges
• Removable bearing brake prevents the bearing from spinning
• Ultra-smooth phenolic resin base prevents damage to the
material
Includes
1 Chip Deflector
1 Vertical Edge Trimming Base
1 8 mm Collet
1 1/4" Collet
1 Wrench
1 Systainer SYS3 M 187 (case)
1 Plug-it Power Cord
Specifications
Drive Shaft Speed 10,000-26,000 rpm
Collet Diameter Range 1/4" - 5/16" (6-8mm)
Routing Stroke 2-3/4"
Power Consumption 720 W/6 Amps 120v
Routing Depth Fine Adjustment Range 1/2"
Weight 4.19 lbs.
Max. Cutter Diameter 1-1/4"
Features:
• Precision depth control
• Variable speed control
• Trim laminate and edgeband or rout grooves
• Possible to flush trim 0 to 45 degree inclined edges
• Removable bearing brake prevents the bearing from spinning
• Ultra-smooth phenolic resin base prevents damage to the
material
• Threaded insert to accept template guides
• Attachable base feeler bearings allows use of bearing-less bits
Includes
2 Collets: 1/4" dia., 5/16" dia.
1 Dust Extraction Hood
1 Standard Threaded Base for US Guide Bushing
1 Plug-It Power Cord
1 Vertical Base
1 1.5 Degree Horizontal Base
1 Feeler Bearing Set
1 Wrench
1 Systainer SYS3 M 187 (case)
Specifications
Drive Shaft Speed 10,000-26,000 rpm
Collet Diameter Range 1/4" - 5/16" (6-8mm)
Power Consumption 720 W/6 Amps 120v
Routing Depth Fine Adjustment Range 1/2"
Weight 4.2 lbs.
Max. Cutter Diameter 1-1/4"
Tool-less base changes transform it from
a vertical to a horizontal position
