Charles McMurray Co. 2021 Catalog

1164 / 1590

Features:
• 1-3/4 hp, 11.0 amp motor provides the power to rout smoothly
through the toughest hardwoods
• Micro-fine depth adjustment ring provides precise depth
adjustments in 1/64" increments and adjusts vertically for
a constant switch/cordset location
• Adjustable, tool-free steel motor cam lock makes depth
adjustment and base changes quick and solid-locking
• Sub-base concentricity gauge included to ensure bit
concentricity for accuracy
• Clear, LEXAN sub-base provides enhanced base durability, bit
visibility, and accepts standard template guide bushings
• Rubber overmolded handles and low center of gravity design
provide comfort, balance, and control
• Dust-Sealed Switch protects against dust ingestion for longer
switch life
• Heavy-duty, precision machined, die-cast aluminum base and
motor housing for durability and low tool weight
• Left or right switch and cordset location provides the ability to
have the switch in your left or right hand
Includes
1 DW616M Motor Pack
1 DW6184 Fixed Base
1 1/4" and 1/2" Collets
1 Sub-base Concentricity Gauge
2 Wrenches
Specifications
Amperage 11.0
No Load RPM 24,500
Collet Capacity 1/2", 1/4"
Max. Tool HP 1.75
Voltage 120V
Weight 7.1 lbs.
No.
1-3/4 hp Fixed Base Router
No.
2-1/4 hp Fixed Base Router
Features:
• 2-1/4 hp, 12.0 amp variable speed motor provides the power
to rout smoothly through the toughest hardwoods
• Micro-fine depth adjustment ring provides precise depth
adjustments in 1/64" increments and adjusts vertically for
a constant switch/cordset location
• Adjustable, tool-free steel motor cam lock makes depth
adjustment and base changes quick and solid-locking
• Clear, LEXAN sub-base provides enhanced base durability, bit
visibility, and accepts standard template guide bushings
• Rubber overmolded handles and low center of gravity design
provide comfort, balance, and control
• Dust-Sealed Switch protects against dust ingestion for longer
switch life
• Heavy-duty, precision machined, die-cast aluminum base and
motor housing for durability and low tool weight
• Left or right switch and cordset location provides the ability to
have the switch in your left or right hand
Includes
1 DW616M Motor Pack
1 DW6184 Fixed Base
1 1/4" and 1/2" Collets
1 Wrench
Specifications
Amperage 12.0
No Load RPM 8,000-24,000
Collet Capacity 1/2", 1/4"
Max. Tool HP 2.25
Voltage 120V
Weight 7.2 lbs.
D-Handle Base for & Routers
D-Handle base has a two-position rubber overmolded handle and low center
of gravity design for comfort, balance and control. Quick release motor
latches provide fast, easy motor pack removal for bit and base changes.
Item No. List Ea.
$215.66
For router bits see catalog pages 1173-1178.
