Charles McMurray Co. 2021 Catalog

1153 / 1590

Portable Dust-Free Sanding System
(Order sander, vacuum & hose separately)
O.D.: Tapers 1-1/2" to 1-1/4"
Connection: 2-1/4"
Specifications
Power 350 W
Input Voltage 100-120 VAC
Speed 4,000 - 10,000 rpm
Noise Level 71 dB
Orbit 3/16"
Weight 2.2 lbs.
No.
5" Electric Random Orbit Sander (DEROS)
Accessories Accessories
Multi-hole disc pad. Hook & Loop backing.
Item No. Size List Ea.
5" $115.25
Item No. Description List Ea.
12' Hose $214.68
Includes
DEROS Sander
Multi-hole Hook & Loop pad
Detachable power cord
Abranet sample pack
Systainer plastic case
Instruction manual
1 Quick Connect Cord: Convenient push-lock connection is molded
into the handle to attach the AC power cord. Cord can easily be replaced
if worn or damaged.
2 Speed Controls: Pressing the soft-touch + or - button will set the
maximum speed of the sander between 4,000 and 10,000 rpm.
3 Throttle Lever: The palm throttle controls the variable speed by
simply pressing down on the lever. When fully depressed, the tool runs
at the maximum set speed up to 10,000 rpm. The throttle can also be
set to act as a simple “on/off" switch.
4 Dust Collection Shroud: The internal brake seal prevents loss of
vacuum efficiency between the sander and the backing pad. The seal
also reduces the tendency for the backing pad to free-spin which can
cause unwanted sand scratches.
5 Ergonomic Benefit: The symmetrical design allows the sander to be
used left or right handed with equal ease. The lightweight, composite
housing is rubber coated to reduce vibration.
6 Vacuum Connection: The secure, internal-thread is designed to
connect 1" I.D. vacuum hoses
1
3
4
6
5
2
No. Dust Extractor
Voltage mains supply 110 - 120V
Mains frequency 60 Hz
Power input 1200 W
Volume flow air 4500 l/min
Vacuum 230 mbar
Noise level, LpA 60 dBA
Container Size 8 Gallon
Dimensions 15-1/4" x 22-1/4" x 22-1/4"
Weight 32 lbs
1 Easily accessible flat filter: Filter can easily be reached through an
opening in the back.
2 High volume container: 30 liters for applications where a lot of
material is extracted.
3 Large wheels: Easy maneuverability on uneven surfaces.
4 High performance motor and turbine: 1200 W motor and 1-stage
turbine creates 250 mbar pressure and 4500 l./min. airflow.
5 Push & Clean Filter Cleaning: Easy way to clean the filter for longer
life time and better performance.
6 Hose storage: The hose is always ready for use.
7 AutoStart function: Dust extractor runs only when the power tool is
running.
1
2
3
4
6
7
5
