Charles McMurray Co. 2021 Catalog

1159 / 1590

No.
Variable Speed Jigsaw Kit
Features:
• Tool-free blade change system – Fast insertion, blade ejection
lever eliminates need to touch hot blade. Most secure jigsaw
clamping system
• Ambidextrous lock-on button – For steady long cuts and user
comfort and control
• Variable speed - Dial sets maximum speed and accelerator
trigger controls operating speed
• Large, sturdy die-cast foot with steel insert and on-board bevel
wrench
• Powerful 7.0-Amp jigsaw – Top jigsaw amp rating
• Exclusive multi-directional blade clamp provides superior grip
of T-shank blades
• Internal precision control - Precision-machined plunging system
and low-vibration design for enhanced accuracy and extremely
smooth operation
• Constant Response™ circuitry – Maintains desired speed for
consistent performance and precision
• Four orbital-action settings -Different blade strokes for smooth
to aggressive cuts
• Adjustable dust blower keeps cutting line clear
• Ergonomic top handlewith soft-grip areas for solid, comfortable
grip
Includes
1 No-Mar Overshoe
1 Anti-Splinter Insert
1 Blade
1 Bevel Wrench
1 Carrying Case
Specifications
Amp 7.0
Bevel Angle Range 45°
Cutting Capacities
Soft Wood 5-7/8"
Aluminum 7/8"
Mild Steel 3/8"
Hertz 60 Hz
Max. Bevel Cut 45°
No Load SPM 500-3,100
Rating 120V
Stroke Length 1"
Weight 5.6 lbs.
Height 7"
Width 4"
No.
Variable Speed Jigsaw Kit
Features:
• The Precision Control™ double-roller system minimizes blade
deflection for excellent cut precision
• Switchable LED lighting for enhanced visibility of cutting area
• Large die-cast magnesium footplate with tool-free adjustment
for fast and easy bevel adjustments
• Easily handles heavy loads
• Versatile variable-speed control includes a dial to set the
maximum speed and an accelerator trigger to control the
operating speed
• Constant Response™ circuitry maintains desired speed for
consistent performance under load
• Bosch-exclusive multi-directional blade clamp provides superior
grip of T-shank blades but does not accept U-shank blades
• Aluminum gearbox with insulated cover
• Tool-less blade-change system allows fast blade insertion
and the blade ejection lever eliminates need to touch hot blade
• Four orbital-action settings provide different blade strokes for
smooth to aggressive cuts
• Fully counterbalanced low-vibration mechanism ensures
extremely smooth operation
• Dust blower with on/off switch for keeping the cut line visible
and free of dust
Includes
3 Assorted Blades
1 Anti-Splinter Insert
1 Plastic Shoe
1 Carrying Case
Specifications
Amp 7.2
Bevel Angle Range 45°
Cutting Capacities
Soft Wood 5-1/2"
Aluminum 7/8"
Mild Steel 3/8"
Hertz 60 Hz
No Load SPM 800-3,000
Rating 120V
Stroke Length 1"
Weight 5.5 lbs.
Height 8-1/2"
Width 4"
