Charles McMurray Co. 2021 Catalog

1108 / 1590

METABOX
Shelf Pins
Item No. List Ea.
$173.26
Drill Bits
Item No. Size List Ea.
5 mm (3/16") $20.74
10 mm (3/8") $33.08
Boring Template Boring Template Kit
Accessory Kit Drill Bits
No.
Kit includes one each:
2.5 mm drill bit extension
6 mm stop collar
#2 x 6" Phillips driver bit
Allen wrench
Steel twist style bits for
TANDEM slide system.
No. Size
3/32"
6 mm
Bore for
rear hooks
Bore pilot holes for locking
device screws at 15° angle
3/32" bit with
extension
6 mm bit
• Pilot bore with 3/32" bit for locking devices
• Bore rear hole for runner hook with 6 mm drill and stop collar
All you need to correctly prepare a drawer for TANDEM runners.
Kit includes template, drill bits, drill bit extension, stop collar,
driver bit and allenwrench. Components also available separately.
Item No. List Kit
BLUM-SLIDE-TEMPLATE $196.26
Components
Item No. Description List Ea.
Template $109.96
Accessory Kit $69.20
3/32" Drill Bit $3.74
6 mm Drill Bit $13.36
No.
Can be used for drawer front, back and
bottom. Locates all fixing points. Can be
used on Aventos, Tandembox, Metabox and Legrabox. Includes
5 mm & 10 mm stop collars and 10 mm marking pin. Drill bits
sold separately.
Templates & Jigs
TANDEM Slides
Shelf Pin Jig with 5 mm Bit
Add shelf pin holes to existing furniture, or build custom shelves
from scratch.
• Six hardened-steel drill guides
• Consistent 1-1/4" (32 mm) spacing
• Compatible with 32 mm cabinet systems
• Aids alignment of concealed hinges and drawer slides
• Connect two jigs without tools
• Onboard storage for bit, pin, wrench
• Drill guide spacing 64 mm to 128 mm
Item No. List Ea.
KMA3232 $82.96
Includes:
A Shelf pin jig base E Indexing pin*
B Dual position fence (removable) F Jig extension
C 5 mm brad-point drill bit G Hex wrench
D Stop collar w/screw set H (4) 5 mm shelf pins
*Indexing pin is double ended for both 1/4" and 5 mm shelf pin holes.
A
B
C
D
E
F
G
H
DOOR
HARDWARE
TOOLS
FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
TOOLS
