Charles McMurray Co. 2021 Catalog

1106 / 1590

QUICKFIX Template for Hinges & Plates
• Locates/matches positions of hinges and plates on cabinets
and doors
• Transfers positions from door-to-cabinet and cabinet-to-
door
• Adjustable stop for various door overlays
• For use with wing or in-line mounting plates
Item No. List Ea.
$282.18
Templates & Jigs
Cabinet Hinges & Baseplates
PlateMate Boring Template
For Face Frame Adapter Plates
• Boring template for all Blum face frame adapter plates.
• Clamps to the frame with cam lever
• Adjustment knob accommodates frame thickness of 5/8" to 1"
• Spacer screws permit quick use without measuring
• Includes 2.5 mm pilot bit and drill extension
Item No. List Ea.
$223.76
adjustable
M4 x 25mm
spacer screws
included
Boring Template for 970A BLUMOTION for Doors
• For pre-boring of BLUMOTION 970A
• Ø10 mm drill bushing for edge boring
• Includes 10 mm stop collar
• Universal bores left and right side of cabinet
• Can also be used with Tip-On for doors
Knock-In Tool for Press-In Hinges
Item No. List Ea.
$164.74
Item No. List Ea.
$68.20
5mm
holes
cursor
Anthony's Hinge Jig
handle
5mm pins
side view
Use for locating the centerline for a hinge. Mounts easily into
5mm holes. Use the cursor to draw a centerline. If the cabinets
don't have 5mm holes, use the pins and align them along the
edge of the cabinet, drill with a 5mm driver bit in the drill guide
and repeat the steps for finding the centerline.
Item No. List Ea.
$15.30
Mounts easily into 5mm
holes. Use the cursor to
draw a centerline.
DOOR
HARDWARE
TOOLS
FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
TOOLS
800.533.0533 2021 1946 1106 Prices subject to change without notice.
