Without ridge, with tightening element. 100 each per box. Sold
per each.
Item No. Finish List Ea.
List Ea.
100
Zinc Alloy
Nickel-Plated $2.40 $1.92
Plastic w/Zinc Alloy
White $1.08 $0.86
Connector Housing w/8 mm Bolt
Item No. Finish List Ea. List St. 100
Nickel-Plated $1.52 $1.24
Without ridge: panels can be inserted by dropping the panel
on top of the bolt and inserting the panel from the side of the
bolt. This allows for the most flexibility in assembly.
Rafix-SE Housings
For wood thicknesses from: 19 mm
Mounting center: 9.5 mm
Drilling Depth: 14.2±02 mm
Dimension A = 1/2 wood thickness
Rafix Connecting Bolts f/5 mm Hole
Zinc-plated steel.
Sold per each.
Item No.
Thread
Length List Ea.
List Ea.
100
8 mm $0.50 $0.40
11mm $0.50 $0.40
Rafix Push Thru Bolt for 5 mm Hole
For Center Panels
Galvanized steel. Sold per each.
Item No.
Panel
Thickness List Ea.
List Ea.
100
19 mm $0.98 $0.78
