Charles McMurray Co. 2023 Catalog

897 / 1645

Wall Cabinet Hanging System
Hanging Strip
Hanging Brackets
Wall mounted hanging strips are 1" wide x 8'2" (2.5 meter) lengths
in galvanized steel.
Item No. Box List Ea.
List Ea.
10
10 $22.26 $18.56
Screw-mounted. Larger hook with metal and plastic interior.
White finish. White covercap included. Order screws (#8 x
1-1/4" FHPH) separately. Sold per each.
Item No. Description Box List Ea.
List Ea.
100
Right Hand 100 $5.72 $4.54
Left Hand 100 $5.72 $4.54
length
23.9
17.2 17.2
50.8 50.8
8.4
16.4 6.2
6
1.8
6
26 8
10
Panel Hanging Systems
OA8745: 1/2" offset x 7/16" drop (.500" x .440")
ZCLIP: 1/4" offset x 7/16" drop (.250" x .440")
Clips are 2-1/2" wide, with holes. Sold in pairs.
Rails are 12'L, 700 lb. load rating, without holes. Sold per each.
Light Duty - Ideal for hanging picture frames, mirrors or
other similar small objects.
Item No. Description Box List
Height when mounted 2-9/32"
Clip w/holes 100 pr $2.34 pr
Rail w/o holes 12 ea $97.14 ea
Medium to Heavy Duty - Ideal for hanging bookshelves,
large mirrors, cabinets, etc.
Height when mounted 3-1/16"
Clip w/holes 100 pr $2.68 pr
Rail w/o holes 12 ea $114.26 ea
®
• Mill finish aluminum
• Designed for two of the sections to wedge together, securely
locking panels in place
• Easily mounts to any type of surface
Screws are not included. Clip can use up to a #10 panhead screw.
Light Duty and Medium to Heavy Duty
Lift-off clearance of 7/16" required for installation and removal
Light to Medium Duty
Lift-off clearance of 5/8" required for installation and removal
3/16" offset x 5/8" drop (.175" x .625")
Clips are 1-1/2" wide, with holes. Sold per each.
Rails are 6' lengths, without holes. Sold per each.
Light to Medium Duty - Ideal for hanging longer objects
such as wall panels, partitions or signs.
Height when mounted 3-1/8"
Clip w/holes 100 ea $1.12 ea
Rail w/o holes 12 ea $25.84 ea
QA8745 ZCLIP
