Charles McMurray Co. 2023 Catalog

753 / 1645

Hybrid Brackets
Surface or Concealed Mounting
• Surface or concealed mounting for floating shelf appearance
• Texture powder-coated finish in black or white
• Non-handed
• Vertical tubular arm: 1-1/2" (width) x 3/4" (thickness)
• Horizontal arm (T-shape): 1-1/2" x 1-1/2"
• Multiple mounting holes on support arm and vertical tube
• Includes plastic finishing caps for tube and screw holes
• Mounting hardware not included
Item No.
(A)
Arm
(B)
Height Finish
Load Rating
(per pair) List Ea.
List Ea.
2
List Ea.
10
12" 12" Black 2,050 $74.70 $66.40 $54.33
12" 12" White 2,050 $64.04 $57.84 $48.46
18" 18" Black 1,780 $113.86 $101.20 $82.80
18" 18" White 1,780 $113.86 $101.20 $82.80
24" 24" Black 1,360 $126.26 $114.04 $95.56
24" 24" White 1,360 $126.26 $114.04 $95.56
Surface Mounting Concealed Mounting
Dimensions
Drywalled
Concealed applications require ripping
a 2"x4" lengthwise, and mounting the
ripped 2"x4" 2 to the side of a standard
2"x4" 1 stud. Bracket is then mounted
to the recessed (ripped) 2"x4".
Install drywall around support arm.
Mounting Detail
1
2
1
Plastic finishing caps to conceal
the bottom of the tube
and the screw holes
are included.
1
2
Finishing Caps
2
SHELF & CLOSET HARDWARE
800.533.0533 753 Prices subject to change without notice.
McMurray.com
