Heavy-Duty Mixer Lift Hardware
Available With or Without Soft-Close
Available With or Without Shelf
Mixer Clearance
Dimensions
Minimum height required: 28". Minimum cabinet depth: 20-1/2".
Recommended spring position
for varying mixer weight
0-20 lbs. 1
20-30 lbs. 2
30-60 lbs. 3
3/8"
2-1/8" 11-3/8"
1-1/2"
4-1/2"
36"
1-1/2"
full back
lowest point
4-3/8"
5"
24"
22-7/16"
tension adjustment
floor
To determine the shelf sizemeasure the distance
between the mounting plates, when installed,
minus 1-1/4". Recommended shelf length is 20",
minimum thickness of 3/4". Mounting plates
are 1" wide.
• Mounts to cabinet side
• Adjustable spring tension and built-in shock dampeners
• Holds appliances up to 60 lbs.
RAS-ML Series fits all cabinet sizes and is available with or without soft-close.
ML Series is designed for 18" base cabinets and has soft-close hardware.
RAS-ML Series-Mixer Lift Hardware Only
Contains left and right-hand lifting arms
and mounting hardware.
Item No. Description List Ea.
Chrome, Standard $240.52
RAS Chrome, Soft-Closing $468.92
Gray, Soft-Closing $468.92
ML Series-Mixer Lift Hardware & Shelf
Contains 1-1/2" thick shelf, left and right-hand
soft-closing lifting arms and mounting hardware.
Item No. Description List Ea.
For 18" face frame cabinet
Chrome w/Maple Shelf $670.02
For 18" frameless cabinet
Gray w/Walnut Shelf $955.90
NOTE: Needs to be installed in full-height
base cabinet, 28" minimum.
Gray with walnut shelf
RAS Chrome Hardware Only
Gray Hardware Only
Chrome with maple shelf
