Maple Pilaster System
• Solid maple pilasters and high-strength metal brackets
• Allows for tool-free, post-installation adjustability
• Load rating 100 lbs.
• Works with side-mount and under-mount slides
• Pilaster available in two widths and multiple lengths
Slides and drawers
are not included.
Pilaster Size
Set No. Width Length List Set
1 set includes 4maple pilasters and 8metal brackets
1-1/4" 20-7/8" $191.50
2-1/2" 20-7/8" $245.82
1-1/4" 27-1/8" $201.46
2-1/2" 27-1/8" $261.93
1set includes4maplepilastersand20metal brackets
1-1/4" 58-5/8" $422.30
2-1/2" 58-5/8" $507.07
Brackets Only, sold per box
Item No. Box Qty List Box
1 Set (4 each) $42.98
20 Sets (80 each) $629.49
Brackets are 1/8"W, deduct 1/4" off drawer width for
the (2) brackets.
Shown with
under-mount
slides
Shown with
side-mount
slides
Insert the bracket pin into the pilaster, swing the slide down
and it locks into place. To remove the slide swing it upward
and pull it toward the front of the cabinet.
Pilasters are pre-drilled
for easy installation
Front brackets have
a shorter pin than
the rear brackets
Brackets are marked for
left or right side
