Charles McMurray Co. 2023 Catalog

Spacers for BLUM Tandem

& Tandembox Slides

White. 100 each per box,

sold per each.

Item No.

Thickness List Each

List Each

100

BB3692-32

1-1/4"

$3.84

$3.20

BB3639-32

1-3/4"

$5.22

$4.34

Drawer Slide Spacers

High strength nylon, natural color. Use with system screws or

#7 wood screws.

Item No.

Width

Box List Each

List Each

Full Box

B580570

13 mm (1/2") 1000 $1.00

$0.75

B580590

3 mm (1/8") 1000 $0.69

$0.51

B602750

19 mm (3/4") 1300 $1.94

$1.43

NOTE: Use spacers on front, middle and rear of each cabinet

profile for adequate support.

Drawer Slide Spacers

B580570 B580590 B602750

Use 3 deep thread systemscrews

to attach runner to spacer and

spacer to cabinet side.

Interior Drawer Bumper

Prevents runners on interior drawers from

marring cabinet doors. High strength white

nylon. Screws not included. Order #6 x 3/4"

FHPH

(MCFPT346)

. 1000 per box.

Item No.

List Each

100

List Each

1000

B600030

$0.44

$0.39

1-1/8" x 3/4"

Spacer Adapter

Can be used with drawer slide spacers shown above to achieve

an extra 1/8" thickness.

Sold per bag.

Item No.

Thickness Bag Color List Bag

BB37000WH

1/8"

50 White $79.80

3/4" x 3/4"

Dynamic Wear Test

100,000 open/close cy-

cles with a total weight

of 75 lbs. on a 22" drawer.

Static Loading Test

100 lbs. applied to a

half extended 22" draw-

er for 1 minute.

Side Pressure Test

A force of 33 lbs. is ap-

plied ten times to a fully

extended 22" drawer.

Testing Standards

Spacers have 2 mounting holes spaced 32 mm apart, 1 euro-

screw hole and 2 holes for a #6 wood screw to mount to the

slide. White.

Price is per each, sold in multiples of 50.

Order screws separately.

Item No.

Thickness Color

List Ea.

500

BB3602T52

Tan $1.38 $1.02

BB3675T52

1-1/2"

Tan $2.28 $1.56

BB3600WH52

1/2"

White $1.40 $1.04

BB3682WH52

3/4"

White $1.30 $0.96

BB3602WH52

White $1.34 $0.98

BB3604WH52

1-1/4"

White $2.74 $2.04

BB3675WH52

1-1/2"

White $3.08 $2.12

3600 1/2"

3682 3/4"

3602 1"

3604 1-1/4"

3675 1-1/2"
