Charles McMurray Co. 2023 Catalog

Double Door Latches

• Eliminates the need for an elbow catch

• Allows hardware to be installed out of the way

• Doors can be closed in any order

• Requires use of a single lock (sold separately)

• Allows two or three-point locking for standard or wardrobe

style double door cabinets when used with a lock

• Easy to use and install

• Exceeds pull force above 150 lbs.

• Black or white finish

Item No.

Lock

Top Bottom

Placement

Mount

Right Door

DL200 DL300

Left Door

DL300 DL200

1. Determine the location of the lock - right or left-hand door

2. Decide where the latch is needed - top or bottom-mount

3. Choose color - black or white

Example:

DL200

with lock (sold separately) on right-

hand door, top mount.

The lock is mounted on the right-hand door. Inside the right-

hand door, install the activator; on the non-locking door,

install the catch.

Install the latch inside the top of the cabinet. The activator

pushes the bolt on the latch to the other side to engage the

catch. The bolt on the catch side is spring-loaded, allowing

the doors to be closed in any order.

Turn the key to lock the other door; both doors are now

secure. The locking door must be opened first to disengage

the bolt in the latch - the bolt will slide back, allowing the

non-locking door (with the catch) to open.

activator

catch

latch

lock (sold

separately)

DL200W DL300W

Kit No.

Finish Box List Kit

List Kit

DL200

Black

$10.88

$8.88

DL300

Black

$10.88

$8.88

DL200W

White

$10.88

$8.88

DL300W

White

$10.88

$8.88

Kit contains one each:

latch, activator and catch.

Order lock & screws separately. Recommended screw

#6x5/8" panhead

(QS7625)

NOTE:

For cabinets taller than 48" it is recommended

to use both top and bottom-mount latches.

How To Order

CABINET LOCKS & CATCHES

800.533.0533

343

Prices subject to change without notice.
