105° Hinges
Full Overlay Hinges
Item No. Description
List Ea.
200
Silent System (Soft-Close)
Screw-on $11.44
Half Overlay Hinges
Item No. Description
List Ea.
200
Silent System (Soft-Close)
Screw-on $11.76
Minimum Reveal Table
Door
Thickness
Cup Distance C
3 4 5 6 7
14 0.3 0.3 0.2 0.2 0.2
15 0.5 0.5 0.4 0.4 0.4
16 0.7 0.7 0.6 0.6 0.5
17 0.9 0.9 0.9 0.8 0.8
18 1.2 1.1 1.1 1.1 1.0
19 1.5 1.4 1.4 1.3 1.3
20 1.8 1.8 1.7 1.6 1.6
21 2.2 2.1 2.0 2.0 1.9
22 2.6 2.5 2.4 2.4 2.3
The table entries refer to doors with an edge
radius of 1 mm. On doors with other radii, the
minimum reveal changes as follows:
Radius 0 mm: Values shown in table + 0.4 mm
Radius 3 mm: Values shown in table - 0.6 mm
Full Overlay Half Overlay
Distance D = C + B - A
= cup distance C + 11.5 mm - overlay A
Distance D = C + B - A
= cup distance C + 3 mm - overlay A
Full Overlay 11.5 mm
Mounting
Plate
Distance
Cup Distance C
3 4 5 6 7
10 mm 4.5 5.5 6.5 7.5 8.5
11 mm 3.5 4.5 5.5 6.5 7.5
12 mm 2.5 3.5 4.5 5.5 6.5
13 mm 1.5 2.5 3.5 4.5 5.5
14 mm 0.5 1.5 2.5 3.5 4.5
15 mm -- 0.5 1.5 2.5 3.5
Overlay
Full Overlay 3 mm
Mounting
Plate
Distance
Cup Distance C
3 4 5 6 7
0.5 mm 5.5 6.5 7.5 8.5 9.5
1.5 mm 4.5 5.5 6.5 7.5 8.5
2.5 mm 3.5 4.5 5.5 6.5 7.5
3.5 mm 2.5 3.5 4.5 5.5 6.5
4.5 mm 1.5 2.5 3.5 4.5 5.5
5.5 mm 0.5 1.5 2.5 3.5 4.5
Overlay
• For door thickness 14 - 22 mm
• Available in Silent System with self-closing feature
• Cup depth 11.5 mm
• Integrated overlay adjustment + 2.5 mm / - 2.5 mm
• Integrated depth adjustment + 2 mm / - 1.5 mm
• Height adjustment at mounting plate
Veosys
System
STAINLESS STEEL, corrosion proof indoor/outdoor hinge
suitable for use in all temperatures.
Screws - Stainless
Steel Flathead Phillips
Veosys hinges use #7 x 5/8"
wood screws.
