Partial Overlay Application (less than 1" overlay)
Full Overlay Applications (1" or greater overlay)
BLUMOTION 971A For COMPACT Hinges
Features
• Adjustable for various door sizes and weights (+5/-5 mm range)
• Installs anywhere on the hinge side of the cabinet
• Nickel-plated, zinc die-cast construction
• Designed for use with Blum COMPACT hinges
Mounts anywhere on the hinge-
side stile of the cabinet using a
1-1/4" screw (or 2" when us-
ing spacer). Note: mechanism
should not contact hinge cup.
Use a Phillips or POZI screw-
driver to adjust the contact
point in or out 5 mm. Adjust
out for larger, heavier doors
or in for smaller, lighter doors.
Thepartial-overlayspacersnaps
ontothesideoftheBLUMOTION
for easier mounting.
One BLUMOTION is enough for
most applications. For larger or
heavier doors two or moremay
be required.
BLUMOTION
hinge
Set No. Box List 1 Set List 125 Sets
125 $9.64 $8.16
Mounting
Adjustment
Max. 2-7/8"
13/16"
15/16"
15/16"
2-7/8"
1-7/16"
Screw attachment
Attachment of
Partial Overlay Spacer
BLUMOTIONS per Door
Polybagged set includes (1) mechanism, (1) partial overlay spacer and (2) #8 screws.
Sold per set.
