Extension Set for TP1934 Drill Guide
For Long Cabinet Handles and Shelf Pins
• Requires TP1934 drill guide, sold separately
• Installs hardware up to 38" c-c (960 mm)
• Included TP-ERA (Extended Ruler Attachment) provides
a stop for drawer fronts up to 42" wide
• Doubles as a portable 32 mm line boring jig
• Reversible for speedy drilling - Simply flip tool over for
repeated settings on door fronts
5 mm case-hardened steel bushings spaced at 32 mm
5 mm drill bit
5 mm
depth stop
extension
bars
extended ruler attachment
allen wrench
Specifications
Max. c-c 38" (960 mm)
Drawers End stop centers on any width of drawer up to 42" depth
Doors Centers on stile and rail minimum width 1/2"
Material Durable aircraft-quality anodized aluminum
Item No. List Ea.
$373.00
Quick, easy centering on drawer fronts up to 42" wide
Can be used as a portable
32 mm shelf pin jig
Adjustable for long pulls up to
38" (960 mm) center to center
• Easily adjusts for different stile widths, and start position
• For knobs or any center pulls up to 305 mm (12")
• Simple T-square design
• Case-hardened 5 mm bushings
• Reversible for left and right-handed parts
Includes:
1 True Position drill guide
2 sliding guides w/thumb screws
1 end stop w/thumb screws
1 hard plastic case
Item No. List Ea.
$593.72
Recommended drill bit - 5 mm brad point.
Item No. List Ea.
$23.06
