Charles McMurray Co. 2023 Catalog

Packaged Sets Include:

1 ea Frame w/Track

2 ea Foam Stops

1 ea Bottom Plate

12 ea Block Clips

1 ea Back Stud

16 ea Trim Clips

2 ea Split Jamb

1 ea Short/Long T-Guide

6 ea Offset Slats

1 ea T-Guide Base

4 ea Fixing Blocks

1 ea Bi-Parting Pin

24 ea Joining Brackets

1 ea Setting Block

Track and extrusions may be cut to length as required -- do

not cut notched end of track. All required fasteners included.

Select Frame

(May be trimmed to size.)

Set No.

Max. Door Size

List Set

CSS4K3068

3'0" x 6'8"

$1,051.26

CSS4K3080

3'0" x 8'0"

$1,154.90

Carriage Adjustment

Calculating

Rough Opening

DH = door height

DW = door width

RO height

DH + 4-1/4"

RO width - single

(DW x 2) + 2"

RO width - bi-parting (DW x 4) + 2"

DOOR

HARDWARE

TOOLS FASTENERS SHOP &

FINISHING

ABRASIVES LACQUERS &

FINISHES

ADHESIVES FURNITURE

HARDWARE

EDGING &

DECOR.WOOD

SHELF &

CLOSET

ORGANIZERS

KITCH./BATH

LIGHTING SLIDES

DOORS &

DRAWERS

LOCKS &

CATCHES

AVENTOS &

LIFTS

CABINET

HINGES

DECORATIVE

HARDWARE

DOOR LOCKS & HARDWARE

800.533.0533

1413a

Prices subject to change without notice.

McMurray.com

02/23

CS Cavity Slider™ Commercial Grade Pocket Door Frames

with Optional SofStop Soft-Close/Soft-Open (2" x 4" Stud Walls)

For installation instructions visit: http://bit.ly/3x5UvGc

• Aluminum extrusion frame with incorporated track,

accommodates 1-3/8" or 1-3/4" thick, 4' x 8' doors

up to 500 lbs. maximum weight

• Suitable for residential and commercial projects,

meets Type 1 construction code

• Heavy duty anodized aluminum track with minimal

clearance prevents carriage wheel jam and track

jumping; track is radiused to reduce friction and

allow dust to be pushed into gutters for smooth

sliding

• Mounting plates feature CarriSnap™ quick release

for easy door installation/removal with no height

adjustment

• Carriages feature large diameter smooth running

ball bearing wheels, hanger bolt allows for 5/16"

vertical height adjustment

Maximum Door Weight: 500 lbs.

Door Thickness: 1-3/8" or 1-3/4"

Stud Thickness: 3-1/2" or 3-5/8"

Corner joining

brackets

for

precisely angled

assembly

Extruded

aluminum

track

built into

frame head unit

Smooth running carriages

with encased ball bearings

(Load rating 500 lbs.)

T-joining

brackets

easily attach

slat to jamb

& back stud

Adjustable

T-Guide

Bottom plate

assembly

Compatible

with 3-1/2"

and 3-5/8"

wood or

steel studs

Door

Thickness

1-3/8" or

1-3/4"

Split Jambs and

slats

use hollow core

technology for superior

rigidity

Aluminum Frame

complies with

Type 1 Construction

Horizontal

Slats

for

added

strength

Trim Clips

for

quick & easy trim

fitting

Select Standard or SofStop

Hardware Pack

(Order one per door.) Includes carriages, mounting plates,

T-Guide, fixing screws and adjusting wrench.

Set No.

Load Rating

List Set

DKM0611 200 lbs. Standard

$266.52

DKM0811 500 lbs. Standard

$503.42

DKS0511

200 lbs. SofStop Soft-Close

$636.68

DKS0711

200 lbs. SofStop Soft-Close/Open $888.39
