Charles McMurray Co. 2023 Catalog

1361 / 1645

Rolling Door Hardware - Round Rail
Accessories
Rail Door Stop
Stops the rolling door from the top instead of the bottom.
Mounts onto the round rail. Includes a rubber ring to protect
door hardware. Fasteners are included.
Note: Additional center floor guides are required to keep door
rolling in a straight path.
Item No. Finish List Ea.
Satin Nickel $44.34
Black $44.34
Bypass Door Bracket Add-On Kit
Kit No. Finish List Kit
Black $83.82
Includes:
1 Wall Mount Bracket
1 Rail Bracket
All necessary fasteners
NOTE: Order 5 kits for 6' rails.
Order 6 kits for 8' rails.
Wall Mount
Bracket Rail Bracket
Height 5-5/8" 2-9/16"
Width 3-1/4" 1"
Projection 3-1/4" 1-1/16"
wall mount bracket
rail bracket
wall mount bracket
rail bracket
Item No. Length Finish List Ea.
4' Oil-Rubbed Bronze $144.04
4' Black $133.20
6' Oil-Rubbed Bronze $204.52
6' Black $193.02
8' Satin Nickel $268.68
8' Oil-Rubbed Bronze $268.64
8' Black $249.62
Splice Kit
1/2" x 1/8" bar $28.28
Separate rail lengths to build custom length doors. Combine any
of the lengths of rail sold here using the splice kit sold below.
Used to mount the rail to the wall. We recommend 16" spacing
between brackets. Sold per each with screws. Choose from short
or long bracket sizes. Shown with rail attached.
Item No. Type Finish List Ea.
Long Satin Nickel $28.04
Long Oil-Rubbed Bronze $28.04
Long Black $24.94
Short Satin Nickel $28.36
Short Black $25.72
Kit No. Finish List Kit
Satin Nickel $61.82
Oil-Rubbed Bronze $61.82
Black $60.50
2-5/8"H x 1"w
1-3/4" projection w/rail
QG203 short bracket
(Doors up to 1-1/2")
2-5/8"H x 3/4"w
2-3/8" projection w/rail
QG201 long bracket
(Doors up to 2-1/4")
1" dia.
Select Round Rail 3
Select Wall Mounting Brackets 4
Select End Stops (2 per kit) 5
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 1361 Prices subject to change without notice.
