Charles McMurray Co. 2023 Catalog

1198 / 1645

JOBSITE SAW PRO
Item No.
Horse
Power Voltage Retail Price
1.5 120 $1,599.00
Prices shown are SawStop's Retail Prices. Discounts not available on SawStop retail prices.
Saw Dimensions Stowed
Dimensions
Saw Dimensions
with Cart
Table
Dimensions
(Extended) Width 31-3/4" Width 29" Width 48"
Depth 28-3/4" Depth 26-1/2" Depth 29" Width 43-3/8"
Height 15-1/2" Height 45" Height 36" Depth 24-5/8"
Includes
1 Collapsible Rolling Cart 1 10" Blade
1 Miter Gauge 1 Zero Clearance Insert
1 JSS Active Dust Collection Blade Guard 1 Standard Brake Cartridge
1 Riving Knife 1 User’s Guide
2 Blade Wrenches 1 Hardware Pack
1 Push Stick 3 Hex Keys (3mm, 4mm, 5mm)
1 High/Low T-Style Fence w/Ergolock 1 Assembly Instructions Poster
Specifications
Motor Configuration 120 VAC 60 Hz, Universal
Amperage 15A
Motor Peak HP 4
Motor Continuous HP 1.5
No Load RPM 4,000
Blade Diameter 10"
Dado Diameter 8"
Max. Depth of Cut, Blade at 0° 3-1/8"
Max. Depth of Cut, Blade at 45° 2-1/8"
Max. Rip Right of Blade-Extended 25-1/2"
Dado Max. Width 13/16"
Bevel Angle Range -1 to 46
Cord Length 116"
Weight - Saw Only 84 lbs.
Weight - With Cart 113 lbs.
• Class leading 24-5/8" table depth for better accuracy
and safer cutting
• Ultimate portability: 113 lbs. with included cart
• Intuitive action extends/collapses cart for transport
• ErgoLock T-Style Fence with 25-1/2" rip capacity
• Superior dust collection
• Powder-coated aluminum table
• On-board accessory storage drawer
One-Turn Elevation
Ground-breaking elevation
system raises or lowers the
blade in just one turn of the
handwheel.
QuickTilt
Tilt the blade easily and quickly
to your ideal angle in 1 degree
increments. Fine tune between
degrees with the Tilt Adjust.
T-Style High/Low Fence
with Ergolock
The T-Glide Fence slides smoothly and locks
firmwith the innovative ErgoLock. TheT-style
design squares on lock-down to increase
accuracy. Extend the OnDemand Shelf for
support when needed.
Advanced Dust Collection
The included Active Dust Collection
Blade Guard protects against kickback
and uses blade turbulence to collect
above-table dust. Under-table shrouding
maximizes dust extraction for a cleaner,
safer work area.
