Charles McMurray Co. 2023 Catalog

1192 / 1645

Compound Miter Saw
Features:
• The Kapex features a rail forward design which increases
precision and creates a compact footprint while preventing
head play for accurate cuts
• Easily align cuts from the left or right side using dual lasers.
The lasers clearly define the material which will be removed
during the cut
• Micro-adjustable bevel angle with up-front rotary knob. Large
bevel scale and fine pointers make it easy to set precise bevel
angles
• Dust extraction up to 91% with behind the cut dust hood and
pivoting 36 mm hose
Includes
1 60 Tooth Universal Blade
1 MiterFast Angle Transfer Device
1 Hold Down Clamp
1 Wrench
Specifications
Crown Moulding Diag. Cut 45°/90° 6-5/8"
Special Cutting Depth 45°/90° (right) 3/4" x 4-3/4"
Special Cutting Depth 45°/90° (left) 1-1/2" x 4-3/4"
Crown Moulding Diag. Cut 90°/90° 6-5/8"
Special Cutting Depth 90°/90° 2-1/4" x 4-3/4"
Blade Diameter 10-1/4"
Power Consumption 1,600 watts/13 amps 120 V AC
Speed 1,400 - 3,400 rpm
Dimensions (W x D x H) 28" x 19-3/4" x 18-1/2"
Work Height 35-1/2"
Weight 47 lbs.
Features:
• Kickback stop reduces risk of injury, may be deactivated for
individual cuts, reactivates when saw is switched back on
• Concentrated torque for fast work progress and increased saw
blade life
• Transparent sliding window provides view of saw blade and
markings for start and end point
• Brushless EC-TECH motor and (2) 18V batteries
• Use with dust collection bag or extractor with Bluetooth®
automatic switch-on
• Precise cuts in materials up to 2-1/8" thick
Includes
1 55" Guide Rail FS 1400
2 BP 18 Li 5.0ASI Battery Pack
1 Chip Collection Bag
1 Hex Key 5 mm
1 HW Fine Tooth Saw Blade W42
1 Rapid Charger TCL 6
1 Sight Window
1 Splinterguard
1 Systainer SYS3 M 437 (case)
Specifications
Dust Extraction Port 1-1/16"/1-7/16"
Battery 2 x 18V/5.00Ah
Speed 2,650 - 3,800/5,200 rpm
Cutting Depth at 45° 1-11/16"
Miter Angle 60°/60°
Blade Diameter 6-1/4"
Cutting Depth 0" to 2-1/8"
Angular Range -1° to 47°
Weight 7.94 lbs.
Manually
deactivated
kickback
stop
06/24
Cordless Track Saw Bluetooth
Item No Description Price Ea.
TSC 55 5.0 KEBI-F-Plus-FS Call/Web
Item No Description Price Ea.
Kapex KS 120 REB Call/Web
