Charles McMurray Co. 2021 Catalog

924a / 1590

Vertical Wall Bed System
NOTE: You must build your own cabinet and door
Wall Bed Set
Item No.
Bed
Size
Load Rating
List Set Dynamic Static
Dbl/Full 400 lbs. 1,000 lbs. $1,358.86
271.92.200 Queen 400 lbs. 1,000 lbs. $2,161.16
Double/Full Set Includes
Frame Safety Brackets
2 Gas Pistons* (1600 Newton)
Mounting Hardware
Recommended Sizes & Weights
Bed Size AverageFront Panel Mattress Slat Kit or
Plywood Sheet
Total Lifting
Capacity
Dbl/Full 80 lbs. 55-80 lbs. 30-35 lbs. 165-195 lbs.
Queen 100 lbs. 65-85 lbs. 30-35 lbs. 195-220 lbs.
NOTE: Wall bed will not operate properly unless the
above weight ranges are adhered to.
• Steel frame bed kit for vertical folding beds
• Available in Queen: 80" x 60" or Double/Full: 75" x 54",
for mattresses up to 10" thick (not included)
• Door brackets attach front panels to support bars
• Easy adjustment of front panels with included height
adjustment screws
• Optional comfort slat system available
• A variety of pistons available for different lifting powers
Optional Comfort Slat Kit
• Easy to install • Flexible curved beechwood slats
• Increases comfort • Frame Material: Steel
Bed Size Item No. List Kit
Double/Full $333.16
Queen 271.92.260 $564.76
Optional Piston Covercaps
Black steel cover caps conceal the
mounting plates and pistons.
Sold per pair.
Item No. List Pair
271.92.250 $249.06
Item No.
Piston
Strength
Average
Front Panel Mattress
Comfort Slat Kit or
Plywood Sheet
Combined Lifting
Capacity List Pair
1500N 75 lbs. 55-70 lbs. 30-35 lbs. 145-160 lbs. $39.59
1600N 80 lbs. 65-80 lbs. 30-35 lbs. 155-170 lbs. $39.59
271.92.270 1700N 85 lbs. 55-75 lbs. 30-35 lbs. 165-185 lbs. $48.22
271.92.271 1800N 95 lbs. 60-80 lbs. 30-35 lbs. 180-195 lbs. $33.52
271.92.272** 1900N 100 lbs. 65-85 lbs. 30-35 lbs. 195-220 lbs. $32.72
271.92.273 2000N 100 lbs. 75-95 lbs. 30-35 lbs. 205-230 lbs. $32.72
271.92.274 2100N 100 lbs. 85-105 lbs. 30-35 lbs. 215-235 lbs. $32.72
271.92.275 2200N 100 lbs. 95-115 lbs. 30-35 lbs. 225-250 lbs. $48.22
*This piston is included in the Double/Full set. **This piston is included in the Queen set.
Optional Gas Pistons
For use if lighter or heavier mattress or front panels are being used. Sold per pair.
08/22
Queen Set Includes
Frame Safety Brackets
2 Gas Pistons** (1900 Newton)
Mounting Hardware
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
FURNITURE HARDWARE
800.533.0533 2021 1946 924a Prices subject to change without notice.
