712 / 1590
1/16" max. rise
3-13/16"
1/16" min.
clearance
45°
door below open
1-3/4"
False Front Tray Hinge (Euro) for Long Trays
Bulk pack 10 pair per box, sold per pair.
Item No.
List Pr.
List Pr.
10
List Pr.
40
6552ETH10$26.06
$23.26
$22.08
Setback 37mm
Hole Pattern 32mm
False Front Tray Hinge
• Self-closing spring keeps false fronts securely closed
• Screwhole locations for face frame wood screw mounting
or euro screw mounting on 64 mm centers with 37 mm set
back
• Less than 2 mm of clearance is needed for the countertop
and no clearance is needed below the false front
1 pair per polybag with wood screws.
Sold per pair.
Item No.
Tray
Length List Pr.
List Pr.
10
List Pr.
40
6552-94-0220<16"
$12.32 $11.00 $10.44
6552-95-022016"+ $11.12 $9.92 $9.42
1"W x 1-3/4"D x 3-13/16"H
False Front Tray Hinge - Soft-Close
50°±2°
1-3/4"
2-5/8"
1-7/8"
3-13/16"
• Easy to install soft-close hinge
• For use with all of Rev-A-Shelf's tip-out trays
• For 1/2" or less overlay application
• 50° opening allows for complete accessibility
• Unique soft-close piston eliminates slamming
• Spring allows the hinge to close firmly and stay closed
• Stiffening ribs provide extra stability and eliminate side play
• Nickel finish,
sold per pair
Item No.
List Pr.
List Pr.
10
List Pr.
40
LD-0220-50SC$41.20
$36.80
$34.92
1"
• Designed for long sink front
or cooktop false panels
• Opening angle can be easily
adjusted from 45 ° to 90°
• Chrome-plated
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &
CLOSET
ORGANIZERS
KITCH./BATH
LIGHTING SLIDES
DOORS &
DRAWERS
LOCKS &
CATCHES
AVENTOS &
LIFTS
CABINET
HINGES
DECORATIVE
HARDWARE
ORGANIZERS - KITCHEN/BATH
800.533.0533
2021
1946
712
Prices subject to change without notice.
CHARLESMCMURRAY.COM
