Maple Pilaster System

• Solid maple pilasters and high-strength metal brackets

• Allows for tool-free, post-installation adjustability

• 100 lb. load capacity

• Works with side-mount and under-mount slides

• Pilaster available in two widths and multiple lengths

Slides and drawers

are not included.

Pilaster Size

Item No.

Width Length

List Set

1 set includes 4maple pilasters and 8metal brackets

XB150N

1-1/4" 20-7/8"

$191.50

XB150W

2-1/2" 20-7/8"

$245.82

XB250N

1-1/4" 27-1/8"

$201.46

XB250W

2-1/2" 27-1/8"

$261.93

1set includes4maplepilastersand20metal brackets

XB550N

1-1/4" 58-5/8"

$422.30

XB550W

2-1/2" 58-5/8"

$507.07

Brackets Only, sold per box

Item No.

Box Qty

List Box

XBONLY1

1 Set (4 each)

$42.98

XBONLY20

20 Sets (80 each)

$629.49

Brackets are 1/8"W,

deduct 1/4" off drawer width for

the (2) brackets

.

Shown with

under-mount

slides

Shown with

side-mount

slides

Insert the bracket pin into the pilaster, swing the slide down

and it locks into place. To remove the slide swing it upward

and pull it toward the front of the cabinet.

Pilasters are pre-drilled

for easy installation

06/22

Front brackets have

a shorter pin than

the rear brackets

Brackets are marked for

left or right side
