448TP Series Wood Pantry Pullout With Soft-Close
(All units ship LTL)
• Heavy-duty gas-assisted soft-close • Fully accessible top shelf
• Tilt adjustment • System hole shelf adjustment
• Shipped ready to assemble • Adjustment screws to center pantry
• Includes slide and all mounting hardware • Pull force is equal to opening a high-end refrigerator
• 450 lbs. rated static, 250 lbs. recommended use with pantry
• Door-mount brackets with micro-adjustment for door alignment
• Rub-bushings included for 1-1/2", 1-5/8", 1-3/4" face frames
Full Access "EURO" Cabinet Application
Minimum cabinet opening = product width + 1/2".
Item No.
Product Dimensions Cabinet Dimensions
No. of
Shelves List Ea. Width
Height
Min.
Height
Max.
Min.
Width
Min.
Height
5" 43-1/4" 51-13/16" 5-1/2" 43-1/2" 5 $1,075.66
5" 50-3/4" 59-5/16" 5-1/2" 51" 6 $1,133.22
5" 58-1/4" 66-13/16" 5-1/2" 58-1/2" 7 $1,168.40
8" 43-1/4" 51-13/16" 8-1/2" 43-1/2" 5 $1,121.28
8" 50-3/4" 59-5/16" 8-1/2" 51" 6 $1,196.34
8" 58-1/4" 66-13/16" 8-1/2" 58-1/2" 7 $1,263.00
11" 43-1/4" 51-13/16" 11-1/2" 43-1/2" 5 $1,257.12
11" 50-3/4" 59-5/16" 11-1/2" 51" 6 $1,343.14
11" 58-1/4" 66-13/16" 11-1/2" 58-1/2" 7 $1,418.54
14" 43-1/4" 51-13/16" 14-1/2" 43-1/2" 5 $1,360.14
14" 50-3/4" 59-5/16" 14-1/2" 51" 6 $1,470.22
14" 58-1/4" 66-13/16" 14-1/2" 58-1/2" 7 $1,571.06
System hole shelf adjustment.
Rear wall can be adjusted
to accommodate a large
range of cabinet heights.
Depth: 22"
LTL ONLY
item on
this page
All
units
ship
LTL
Adjustable rub-
bushings prevent
side-to-side move-
ment and frame
rubbing. The easy
nail-in and threaded
designs allow you to
adjust the bushing
for 1-1/2"
face frame
for 1-5/8"
face frame
for 1-3/4"
face frame
to fit your desired space and the felt covering
protects your pullout from wear.
spacer
adjustable
rub bushing
adjustable
rub bushing
spacer
spacer
spacer
adjustable
back
stretcher rail
Vertical Adjustment
450lb Static Load Gas-assisted Soft-close Slide
Horizontal Adjustment
14" WIDE
PANTRY
Example:
16-1/2"W
cabinet
opening
NOTES: Wider cabinet must be blocked out on both sides
of pantry. Rub bushings must be used. Stretcher rail must
be installed at the top of cabinet opening.
