Polymer Kidney Shaped Lazy Susans - Independent Rotating
Two independently rotating shelves, 1" diameter chrome-plated steel tubing, chrome
hub, telescoping upper shaft, and zinc die-cast hardware components.
Each shelf is supported by a positioner assembly attached to a steel center shaft rather
than to the cabinet door. Shelves turn independently of one another and automatically
self-locate from 30° either side of their original position. Loosening one screw allows
for shelf adjustment. The all-steel pivot hardware system adjusts from the top to allow
full use of the cabinet space at the bottom. Telescoping chrome-plated center shaft
will fit cabinets from 26 to 32" and can be cut for shorter cabinets. Almond (AM) and
white (WH) finishes.
Accessories
Item No. A B C D List Set
Almond
3" 4-11/16" 18-5/8" 28" $197.72
4-1/4" 6-7/16" 22-7/16" 32" $210.92
White
1-3/4" 2-13/16" 11-13/16" 18" $170.00
1-1/2" 2-5/16" 14-5/16" 24" $166.06
3" 4-11/16" 18-5/8" 28" $194.42
4-1/4" 6-7/16" 22-7/16" 32" $216.08
L
H
upper pivot support
(6000-91-2)
locking screw
(M2405-409-2)
shaft locking screw
(M2408-409-2)
shaft (6470-96-2208-26)
shaft locking screw
(M2408-409-2) bottom positioner
(6260-95-2)
shelf support
(6470-07-2)
upper positioner
(6260-95-2)
upper shaft assembly
(6470-93-0904-26) 1/2" CL.
(REF)
R
A
B
A
D
3/4" REF.
face frame
of cabinet
3/4" CL.
(REF)
3/4" CL.
(REF)
Item No. Shelf
Height "H"
Spill
Lip "L"
Center of
Rotation "A"
Tray
Radius "R"
Cabinet
Opening "B"
Cabinet
Depth "D"
6472-18-52 1-19/64" 3/4" 2-1/4" 9" 6-13/16" 11-3/4"
6472-24-52 1-53/64" 3/4" 2" 12" 10-1/16" 14-1/2"
6472-28-52 1-53/64" 1" 3-1/2" 14" 10-9/16" 18"
6472-32-52 1-53/64" 1" 4-3/4" 16" 11-3/8" 21-1/4"
Weight Capacity: These lazy susans are tested to exceed BHMA Class
1 specs: 20 lbs. per square foot at 75K cycles (120° rotation).
Item No. List Ea.
Extra long post 70-1/2" x 1"
$111.28
Hardware set only (includes 26"-32" post)
$179.46
