Polymer Full Round Sets
Dependent Rotating
Polymer full circle sets feature a 3/4" diameter zinc, telescoping
shaft system. Adjusts from the top to allow full use of space in
the bottom of the cabinet. Loosening one locking screw allows
for adjustment of shelves. White finish.
6013 Revolving Full Round 3-Shelf
Sets-
Same as two shelf set but with three
shelves and 38" to 46" adjustable post.
1 per box.
Item No. Diam. List Set
White
18" $162.44
20" $183.00
Item No. Diam. List Set
18" $104.42
20" $122.10
24" $147.20
28" $153.38
6012Revolving Full Round 2-Shelf
Sets-
Contains two (2) shelves, center shaft,
top and bottom pivots, complete with
screws. 1 per box.
Accommodates heights from 24-31".
Polymer Full Round Sets
Independent Rotating
Extra Posts, 3/4" dia.
Item No. Size List Ea.
36"* $42.46
*Not adjustable.
Polymer 2-shelf independently rotating unit. 1" diameter chrome
plated shaft system with height adjustment of 26-32". Available
in white (WH).
Item No. Diam. List Set
16" $199.84
28" $292.54
32" $288.52
Extra Long Post 70-1/2" x 1"
Item No. List Ea.
$111.28
pivot 6000-90-2
shelves
collar locking screw
M2305-287-2
upper shaft assembly
6120-93-1200-2
pivot 6000-90-2
1/2" wood screw
F0808-26-2 (8/set)
collar assembly
6120-92-2
set screw
M2408-409-2
full circle
lower center shaft
6020-97-2100-2
Outer edge of shelf:
1-1/2"
Height of lip: 3/4"
For 5-shelf pantry set see catalog page 623.
Weight Capacity: These lazy susans are tested to exceed BHMA Class 1
specs: 20 lbs. per square foot at 75K cycles (120° rotation).
Weight Capacity: These lazy susans are tested to exceed BHMA Class 1
specs: 20 lbs. per square foot at 75K cycles (120° rotation).
