Charles McMurray Co. 2021 Catalog

560b / 1590

Changing your light source’s color temperature is easy with White
Tunable (CCT - Correlated Color Temperature) FlexTape LED liginting.
Select between a warmer temperature that highlights natural wood
grains and earth tones or cool to highlight whites.
CCT Power Pockit®
6 Output Adaptor
Tunable
Remote
CCT Power Pockit Typical Setup
Universal Receiver
LIGHTING
800.533.0533 2021 1946 560b Prices subject to change without notice.
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
Power Pockit® 4W CCT LED Lights
Required Items
Light Fixtures
Item No. Finish Type List Ea.
Black Puck Light $139.72
Nickel Puck Light $139.72
White Puck Light $139.72
Universal Receiver
Item No. Description List Ea.
Parent Controller $253.10
Power Supply (transformers - choose one)
Item No. Description List Ea.
18W 12VDC $106.74
60W 12VDC Dimmable $175.66
NOTES: For use with 96W Class 2 or LPS 24V power
supply, not included. See pg. 560c for specifications.
• Linkable up to 24 fixtures
• Aluminum die-cast construction, with milk lens
• Wide 105° angle of light
• White tunable from 2700K - 6500K
• Built-in dimmable driver
• Dimmable to 50% by standard LED wall dimmers
• Surface or recess mounting
Specifications
Wattage 4W
Lumens 2700K - 236 : 6500K - 280
Efficacy (lm/W) 2700K - 59 : 6500K - 70
Input Voltage 24V
Lamp Life 50,000 Hours
Max. Per 96W
Power Supply 24 Fixtures
Mounting Surface/Recess
Warranty 5 Year
Certifications
Beam Angle 105°
Optional Items
Item No. Description List Ea.
Child Controller/Receiver $228.86
Wireless Wall Dimmer $259.36
Output Adaptor Cord $66.44
24V System LED
Front Side
2-1/2"
mounting ring
03/22
Includes light, 79" attached
starter cord (with 4-pin
connector), and surface
mounting ring.
Universal Receivers allow for
precision color tuning.
Use Parent Controller for the first run
of lights. Use Child Receiver for each
additional run of lights.
See page 560a for available accessories.
See pg. 1135 for hole saws
