Charles McMurray Co. 2021 Catalog

535 / 1590

Keyboard Drawer
• 28.75" Lycra Gel/PVC cushion wrist-rest wraps around
the front edges of drawer
• Integral ambidextrous mousing surface inside tray
• Precision steel ball-bearing slide assembly without lockout
• Tray size: 25-3/4" x 10"
• Load rating: 75 lbs. (BHMA, KCMA, and BIFMA applications)
• Clearance: Fits 29" wide spaces
• Bracket Mounting: Widths 29" or greater; outboard position
Widths 26-3/4" or less; inboard position
Item No. List Ea. List Ea. 3
$290.08 $247.96
Keyboard and Mouse Tray
• 3/4 extension slide
• Keyboard tray, cushioned wrist-rest and mouse-pad tray
• Tray lock-in and lock-out
• Precision steel ball-bearing movement
• Metal ball-retainer holds 3 steel ball-bearings per inch of race
• Keyboard tray and mouse tray are cold-rolled steel
• Wrist-rest is a PVC compound
• 7-position mounting brackets allow for installation at a variety of
heights
• Cushioned wrist-rest is adjustable to 5 different angles
• Built-in mouse-pad tray can be accessed by left or right-handed users
• The tray accepts standard rubberized mouse pads which may be
permanently attached and stored inside when the tray is closed
• Black finish
Min. mounting space required:
With brackets mounted outboard:f/widths greater than 24"
With brackets mounted inboard: f/widths less than 24"
Load Rating: 75 lb. Class (BHMA, KCMA & BIFMA applications)
Overall drop height: adjustable from 2-11/32 to 4-1/4"
Tray Size: 21-1/4"w x 11-1/4"d
Total Depth including Slide: 19"
Mouse Tray Extension: 8-1/2"
Clearance fits 24" wide knee space under desk.
Item No. Finish List Ea. List Ea. 5
Black $403.06 $344.54
Mounting Surface
30-1/4"
21-3/4"
1-21/32" min.
3" max.
(7 positions) 2-19/32" min.
4-1/4" max.
