Charles McMurray Co. 2021 Catalog

526 / 1590

EKU-CLIPO 16 H Inslide
Sliding Cabinet Door System for Wood Doors
Single Running Top Rails
Rotating fasteners for particleboard
(not suitable for hardwood).
Lower Guide Rail
Guide rail is barbed. Black plastic. 2.5m long (8', 2-7/16").
Hardware set includes
hardware for 2 doors:
4 running gears
4 housings, screw-on
2 track stoppers
2 guides
1 soft stop, screw-on
Soft stop, screw mounting.
Gray plastic.
Track stopper, for top tracks.
Gray plastic.
Guide for mounting in drilled
holes. Black plastic.
Running gear snaps into
housing. Black plastic.
Housing for screw mounting.
Black plastic.
Hardware Set Components
Order hardware set, upper running rail and lower guide rail separately.
Item No. Description List Ea.
Hardware Set $253.06
Single Running Top Rail, Screw-on $124.56
Single Running Top Rail, Rotating Fasteners $189.78
Lower Guide Rail $43.72
• Maximum door weight: 35 lbs.
• Maximum door height: 1400 mm (55-1/8”)
• Maximum door width: 1000 mm (39-3/8”)
• Door thickness: 16 and 19 mm (5/8” and 3/4”)
• Height adjustment: +2/-1 mm (+1/16”/-1/32”)
• Running gears with clip-mounting, plastic rollers with metal axles
• Quick door mounting
• No guide rails in the floor
• A wood cover panel is not needed
19
Pre-drilled for screw mounting.
Recommended screw #4 flathead.
• Bright aluminum finish
• Length: 2.5 m (8' 2-7/16")
• Minimum cabinet top thickness 19 mm (3/4")
No. 405.87.082
No. 405.87.092
No. 405.98.517
