Charles McMurray Co. 2021 Catalog

471 / 1590

METABOX 320M 3-3/8" Height
3/4 Extension, Self-Closing
100 lbs. Static, 75 lbs. Dynamic
BLUMOTION Compatible
White (WH) epoxy-coated steel. 10 pair per box. Includes cabinet
and drawer profiles only. Order front fixing brackets and
screws separately.
Item No. Length List Pr.
270mm (11") $24.30
350mm (14") $20.32
400mm (16") $20.04
450mm (18") $20.40
500mm (20") $20.74
550mm (22") $22.32
Item No. Description Box List Pair
Front - Clip, Screw-On 250 $7.52
Front - Clip, Press-In* 250 $7.84
Front - Clip, EXPANDO 250 $8.64
Front - Screw-On 250 $4.68
Front - Press-In* 250 $5.44
H Interior - Screw-On 100 $9.92
*Use insertion ram BMZM0092.01 (special order).
Front Fixing Brackets
Front Fixing Brackets
Clip
Screw-on
Nickel-plated steel
Clip
Press-In
Nickel-plated steel
Clip
EXPANDO Dowels
Nickel-plated steel
Screw-on
Nickel-plated steel
Press-in
Nickel-plated steel
Front & Interior Fixing Brackets
Interior Fixing
Brackets
(For interior rollouts)
Screw-On
White nylon
C15
drawer profile
front fixing brackets
cabinet profile
assembly
prongs
Complete specifications are
available at
Screws
For profiles: Flathead phillips tapping #6 x 1/2"
For C15: Euro screw 11.5mm w/7mm head, pozidrive
For brackets: Flathead phillips tapping #6 x 5/8" (MCFPT586)
