File Slots
Inside Grooves
Dividers
Scoop
Cut Outs & Boring
Bottom Placement
Materials
and Options
Features & Options
Side Material Options
n
Melamine:
White, Black, Almond, Hard Rock
Maple, Anigre Maple, Fusion Maple, Custom Grey,
Formaldehyde-Free White. Other Melamine colors
available upon request.
½",
5
/
8
"
,
¾"
n
Baltic Birch:
UV Pre-finished, Unfinished. 12mm,
15mm, 18mm
n
ApplePly:
½"
Maple in NovaMax UV Pre-finished or
Unfinished. Also available in Walnut, Mahogany,
Red Oak, White Oak and Cherry.
n
PremiumWhite Maple:
UV Pre-finished, Unfinished,
Finished after assembly.
½",
5
/
8
"
n
White Maple:
UV Pre-finished, Unfinished,
Finished after assembly.
½",
5
/
8
"
n
Solid Woods:
Cherry, Walnut, Alder, Oak (White or Red),
Aromatic Cedar, Birch (White, Natural or Paint Grade),
Mahogany, Beech, Pine (Clear or #2), Bamboo. Other
solidwoods available upon request.
½",
5
/
8
"
Bottom Material Options
n
MDF:
¼", ½"
n
Maple Ply:
Pre-finished, Unfinished.
¼",
3
/
8
"
,
½"
n
Birch Ply:
Pre-finished, Unfinished. 5.2mm, 12mm, 15mm
n
Eurofoil:
Black, White.
¼"
n
Melamine:
Almond, Black, White, Hard Rock Maple:
¼", ½",
5
/
8
",
3
/
4
"
Antique White, Formaldehyde-Free White,
Anigre Maple, Custom Grey, Fog Grey:
¼", ½"
n
Unfinished Plys:
Cherry, Walnut, Alder, Oak (White or
Red), Aromatic Cedar, Birch (White or Natural),
Mahogany, Beech, Pine (Clear or #2), Bamboo. Other
bottommaterials available upon request.
¼",
3
/
8
"
,
½"
Learnmore at
DBSdrawers.com
Assembly Options
n
Assembled:
Drawer bottoms are pin nailed and hot melted after assembly
n
Knock Down:
With or without bottoms
Corner Construction
n
Dovetail:
Minimum height 2." Maximum height 15", in whole and half inch
increments or a set up may apply.
n
Dowel:
Minimum height 2". Maximum height 28". Custom heights ±
1
/
8
"
,
wooden
6mm dowels, glued.
n
Butt Joint:
Minimum height 1." Open maximum height, custom heights ±
1
/
8
"
,
rabbeted, glued and nailed. Hot melt extra.
n
French Dovetail:
Minimum height 1
½".
Maximum height,10".
Bottom Construction
n
Let in 4 sides
n
Let in 3 sides
n
Let in 2 sides
n
Bottommount
File Slots and/or Bars
n
Lateral
n
Legal
n
Letter
n
Both
Dividers
n
Removable or permanent
n
Dadoes or nailed
n
1
/
4
"
,
½", ¾"
thickness
Grooves/Kerfs
n
Horizontal
n
Vertical
Drilling
n
For application of faces and hardware
Scoop
n
8 standard options as well as any custom scoop
Notching, Drilling & Locking Devices
n
To facilitate different types of undermount guides
Pull Outs
n
Four Slope Style options available
n
Integrated Lipped Faces:
Lip can be any dimension from
1
/
8
" up.
Front corners are dovetailed or nailed and the back corners can be any of
our available options.
Corner Drawers/Angle Drawers
n
Many options available.
Contact your customer service representative.
