Double Door Latch
• Eliminates the need for an elbow catch
• Allows hardware to be installed out of the way
• Doors can be closed in any order
• Requires use of a single lock (sold separately)
• Allows two or three-point locking for standard or wardrobe
style double door cabinets when used with a lock
• Easy to use and install
• Exceeds pull force above 150 lbs.
• Black or white finish
Example: with lock (sold separately) on right-
hand door, top mount.
The lock is mounted on the right-hand door. Inside the right-
hand door, install the activator; on the non-locking door,
install the catch.
Install the latch inside the top of the cabinet. The activator
pushes the bolt on the latch to the other side to engage the
catch. The bolt on the catch side is spring-loaded, allowing
the doors to be closed in any order.
Turn the key to lock the other door; both doors are now
secure. The locking door must be opened first to disengage
the bolt in the latch - the bolt will slide back, allowing the
non-locking door (with the catch) to open.
activator catch latch
lock (sold
separately)
Item No. Finish Box List Kit
List Kit
50
Black 50 $10.56 $8.62
White 50 $10.56 $8.62
Black 50 $10.56 $8.62
White 50 $10.56 $8.62
Kit contains one each: latch, activator and catch.
Order lock & screws separately. Recommended screw
#6x5/8" panhead .
NOTE: For cabinets taller than 48" it is recommended
to use both top and bottom-mount latches.
Item No.
Lock Top Bottom
Placement Mount Mount
Right Door
Left Door
1. Determine the location of the lock - right or left-hand door
2. Decide where the latch is needed - top or bottom-mount
3. Choose color - black or white
How To Order
