Charles McMurray Co. 2021 Catalog

278 / 1590

Mortise Sewing Machine/Folding Table Hinge
Self-supporting hinge. 30 mm x 65 mm (1.18"x2.60").
Sold per each. Screws not included. Recommended screws: #6
FHPH.
Item No. Finish Box List Ea. List Ea. 10
Polished Nickel 10 $39.00 $31.84
• Flaps can be fitted later when bottom panel and flap
element are assembled separately
• Quality grades to EN 15570, Level 2
• Flap alignment through adjustment of height, sides and
depth
• Three fixing screws (included) in both the bottom panel
and the flap element ensure firm and accurate attachment
• Without height adjustment, bottom panel and flap are
flush on the inside when open
• Nickel-plated zinc die-cast
100 each per box with screws. Sold per each.
Item No. Finish Box List Ea. List Ea. 100
Nickel 100 $14.50 $16.74
Flap Hinge Markant 11
drilling pattern
Reveal Dimensions
Flap
Thickness
(TD)
Minimum
Reveal
(SF)
16 mm 1.0 mm
17 mm 2.0 mm
18 mm 3.0 mm
19 mm 3.5 mm
20 mm 4.5 mm
