110° Opening Short Arm w/Baseplate
1/2" Overlay
1/2" overlay doweled hinge. 35 mm hinge cup. 2-way adjustable.
Dowels are 45 mm apart.
Item No. Box List Ea. List Ea. 200
200 $3.02 $2.50
105° Opening Short Arm w/Baseplate
1/2" Overlay
105° Opening Short Arm No Baseplate
1-1/4" Overlay, Soft-Closing
1/2" overlay doweled hinge with baseplate. Dowels are 45 mm
apart. Order screws separately.
Item No. Description Box List Ea.
List Ea.
200
Dowel 200 ea $3.88 $3.20
Screws
Item No. Description List c
#6 x 5/8" FHPH $4.64
#8 x 3/4" TRPH $9.26
9.5
Ø35
Ø8
45
Screws not included.
Each hinge requires: 6ea #6x5/8" panhead screws
2ea #8x1/2" washerhead screws .
Item No. Box List Ea. List Ea. 100
100 $22.42 $18.61
• Surface mounted
• Works on all doors; Flush overlay, 3/8" inset, full inset
• Fits doors up to 3/4" thick
• 4-way adjustable
Surface Mounted Concealed Hinge
165° Opening, Self-Closing
3/4" Overlay
1-3/16" 7/16"
1-7/8" 1-13/16"
4-3/16" 3-7/8"
1-5/8"
Cabinet Door
3/32"
Straight EdgeCabinet
Door
*3/4" thick door
11/16" 3/8"
1-7/8" 1-13/16"
4-3/16" 3-7/8"
9/16"
Cabinet Door
1/8"
Straight EdgeCabinet Door
3/8"
3/4"
4-3/16"
washerhead
screws here
5/16"
1-1/4"
4-3/4"
2-3/4" 1-13/16"
Cabinet Door
2-7/16"
Straight Edge
Cabinet
Door
3/8" Inset
Full Inset
1-1/4" overlay doweled hinge. 35 mm hinge cup. 4-way
adjustable. Dowels are 45 mm apart.
Item No. Description List Ea.
List Ea.
50
List Ea.
200
H297-D-SC Doweled $5.96 $5.56 $4.90
