184a / 1590
Extension Set for TP1934 Drill Guide
For Long Cabinet Handles and Shelf Pins
• Requires TP1934 drill guide, sold separately
• Installs hardware up to 38" c-c (960 mm)
• Included TP-ERA (Extended Ruler Attachment) provides
a stop for drawer fronts up to 42" wide
• Doubles as a portable 32 mm line boring jig
• Reversible for speedy drilling - Simply flip tool over for
repeated settings on door fronts
5 mm case-hardened steel bushings spaced at 32 mm
5 mm drill bit
5 mm
depth stop
double bracket
extension
bars
extended ruler attachment
allen wrench
Specifications
Max. c-c 38" (960 mm)
Drawers End stop centers on any width of drawer up to 42" depth
Doors Centers on stile and rail minimum width 1/2"
Material Durable aircraft-quality anodized aluminum
Item No.
List Ea.
TP2312-NC$350.94
Quick, easy centering on drawer fronts up to 42" wide
Adjustable for long pulls up to
38" (960 mm) center to center
Can be used as a portable
32 mm shelf pin jig
06/21
TP1934 drill guide sold separately.
See catalog page 184.
