Charles McMurray Co. 2021 Catalog

1379 / 1590

0PF/HD Commercial Grade Pocket Door Frames
(2" x 4" stud walls)
Uprights for Taller Doors
Set includes 2 uprights & 1 floor bracket 511590 (for 1-3/8" door)
Item No. Door Height Stud Length List Set
96" 100-1/8" $93.86
4'0" doors require 3 upright sets; smaller doors require 2 sets
per frame.
• Precision extruded jump-proof box track
• Solid wood header section
• Self-adjusting floor anchors
• Minimum wall structure: 3-1/2"
• Studs - Heavy gauge steel-wrapped split studs
All steel
split studs
Self-Adjusting Floor Brackets
Pocket accepts 1"-1-3/4" thick doors,
no adapter required
100 Series box
track Components
NOTES:
For soft-close hardware see page 1354.
Converging door application requires JH1555PPK3 kit.
For Johnson pocket door accessories see pages 1383-1389.
eos are available at
under the Resources tab.
Wrench
Guides
(2/St, White) Bumper
Hanger, Ball-Bearing
For 200 Lb., 1" Wheels
Hanger
For 125 Lb., 1" Wheels
Item No. Description Box List Ea.
Hanger (pair) 50pr $16.44
Hanger w/Ball Bearings (pair) 50pr $31.98
Hanger w/Ball Bearings (bulk) 50ea $16.22
Bumper 100ea $0.90
Guides (2/st) 100st $1.16
Wrench 100ea $1.10
1" X 3" 1" X 3"
Packaged Sets Include
Header (factory assembled)
1 ea 100 Series track
1 ea 511588 passage end jamb bracket
1 ea 511586 pocket end jamb bracket
2 ea 511590 1-3/8" door floor brackets (3 ea in 4'0" sets)
1 st guides 2/set
1 ea bumper
1 ea wrench
1 pk Mounting screws
125 lb. sets also include - hangers & studs
2 ea hangers
4 ea All-steel split stud lengths
200 lb. sets also include - hangers, studs, shims & brackets
3'0" sets 4'0" sets
2 ea 2 ea hangers
4 ea 6 ea All-steel split stud lengths
JH1575PPK3 adapter components
4 ea 6 ea Shims
2 ea 3 ea 511593 floor brackets for 1-3/4" door
511588
511590
511586
split
studs on
PF series
Packaged Sets
Item No. Door Size Rough Opening List Set
For doors up to 125 lbs.
JH152068PF 2'0" x 6'8" 49" x 84-1/2" $215.80
JH152468PF 2'4" x 6'8" 57" x 84-1/2" $221.62
JH152668PF* 2'6" x 6'8" 61" x 84-1/2" $225.24
JH152868PF 2'8" x 6'8" 65" x 84-1/2" $227.32
JH153068PF* 3'0" x 6'8" 73" x 84-1/2" $233.76
For 1-3/4" doors order JH1575PPK3 adapter kit separately.
For 200 lb. doors
JH152480HD 2'4" x 8'0" 57" x 100-1/2" $274.86
JH152680HD* 2'6" x 8'0" 61" x 100-1/2" $275.54
JH152880HD 2'8" x 8'0" 65" x 100-1/2" $278.44
JH153070HD 3'0" x 7'0" 73" x 88-1/2" $257.20
JH153080HD* 3'0" x 8'0" 73" x 100-1/2" $288.78
JH154070HD 4'0" x 7'0" 97" x 88-1/2" $426.18
JH154080HD 4'0" x 8'0" 97" x 100-1/2" $466.08
*Header is pre-marked to cut for narrower openings.
Maximum Weight with JH1120 hangers: 125 lbs. per door
Maximum Weight with JH1125 hangers: 200 lbs. per door
Minimum Door Thickness: 1"
Option Available
511590
Upright
08/22
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 2021 1946 1379 Prices subject to change without notice.
