Charles McMurray Co. 2021 Catalog

1355 / 1590

JH200 Series Wall Mount Application
Using JH2006 Bracket
LTL ONLY
item on
this page
2-SNAP IN PLA
Shown with track
mounted
to bracket.
JH2006 wall mount bracket
includes set screw, mounting
screw and allen wrench.
2.56"
3"
2.25"
1.125"
Bracket
Item No. Box List Ea. List Ea. 10
10 $31.70 $29.64
200 Series Track
Item No. Length Box List Ea. List Ea. 5
72" 5 $76.10 $64.68
96" 5 $100.10 $85.10
120" 5 $132.60 $112.02
144" 5 $150.22 $127.68
192" 5 $198.78 $168.96
* Must ship LTL
1"
5/16"
Single Door Guide
hanger
3"L x 2"H x 1-5/16"W
1" dia. wheels.
Hardware
Item No. Description Box List Ea.
Wall Mount Door Guide 25 ea $2.58
Hanger 400 lb. (pair) 25 pr $71.54
Hanger-Side Mount 1-3/8" 50 ea $45.60
Hanger-Side Mount 1-3/4" 50 ea $45.60
Single Guide 25 ea $5.02
Track Stop 25 ea $8.58
Track Stop
Maximum weight: 400 lbs. per door
Minimum door thickness: 1-1/8"
Minimum 1 bracket per 16" of track length
• Jump-proof extruded aluminum, heavy-duty I-beam track
• Smooth rolling ball-bearing 4-wheel hangers
• Heavy-duty extruded aluminum mounting brackets can be
positioned along the track to anchor into wall studs
• Commercial grade; also suitable for residential applications
Order brackets, track and hardware (hangers, door
guide, track stop and door catch) separately.
NOTES:
For flush pulls see page 1316
Installation instructions and videos are available at
under the Resources tab.
This track can also be used for:
Pocket Doors......... page 1378
Bypass Doors........ page 1364
Folding Doors........ page 1392
Hardware
Wall Mount Door
Guide
Item No. Description Series Box List Ea.
List Ea.
Full Box
Track Stop 2006,2610 25 $10.14 $8.58
JH2055
Track Stop
hanger
Side mount f/1-3/8" doors.
1" dia. wheels.
hanger
Side mount f/1-3/4" doors.
1" dia. wheels.
Option Available
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 2021 1946 1355 Prices subject to change without notice.
