Charles McMurray Co. 2021 Catalog

1336 / 1590

Low-Profile hardware set Low-Profile Hardware Set Includes*
2 carrier assemblies (each assembly includes 1 channel,1 support insert, 1 carrier, 1 end cap)
2 end stops
1 floor guide
1 wrench
screws & installation instructions
Set includes 2 of these.
Wall Mount
Top Line HD Series Single/Bi-Parting Doors
For Doors Minimum 1", Up To 325 lbs. Each
Bracket, track & hardware sold separately
Wall Mount Bracket
Item No. Length Box List Ea.
List Ea.
Full Box
8' 5 ea $287.02 $243.98
Track
Item No. Length Box List Ea.
List Ea.
Full Box
6' 5 ea $325.04 $276.28
8' 5 ea $358.98 $305.14
12' 5 ea $502.80 $424.78
Standard Hardware Set Includes
2 carriers w/ball-bearing wheels & adjustable pendant bolts
2 top plates
2 end stop catches
1 floor guide (7015)
screws & installation instructions
• Ideal for medium and heavy-duty single and bi-parting applications
• Anodized aluminum
• For 1" through 2" doors
• Screws and nuts attach track to wall mount bracket
• End caps required (order separately)
Hardware
Item No. Description Box List Set
List Set
Full Box
Hardware Sets
Low-Profile* 5 sets $747.18 $633.20
Standard 5 sets $197.80 $167.10
wall mount bracket
track
Standard hardware set
end cap
Shown with Standard Hardware
Shown with Standard Hardware
For Silent System HD
Soft-Close Hardware
see page 1339.
* Low-profile option requires a minimum door thickness of 1-3/8".
